Collapsing Movable Wooden Folding Sound Proof Partitions Noise And Heat Reduction
Product Details:
| Place of Origin: | Guangzhou,China |
| Brand Name: | BUNGE |
| Certification: | ASTM E90 |
| Model Number: | 85 mm sound proof partitions |
Payment & Shipping Terms:
| Minimum Order Quantity: | No MOQ |
|---|---|
| Price: | US $78-108 per square meter. |
| Packaging Details: | Paper carton,outside with wooden boxes. |
| Delivery Time: | 7-15 days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Panel Material: | MDF+Laminate | Feature: | Acoustic,sound Proofing |
|---|---|---|---|
| Thickness: | 85 Mm(3 1/4 Inch) | Size: | Accept Customized |
| Colors: | Can Be Customized | Service: | Free Sample And Design |
| Width: | 800-1220 Mm | Product Name: | Sound Proof Partitions |
| Height: | 20000-16000 Mm | ||
| High Light: | sounproof folding partition,movable sound proof partitions |
||
Product Description
Decorative Acoustic Operable Walls Sound Proof Movable Partition Walls for Ballroom
Sound proof partitions details
| Height (maximum height) | 2000-16000 mm |
| Width | 650~~1200mm |
| Thickness | 85 mm |
| Left and right telescoping | 140 mm |
| Stretching up and down | 45 mm |
| Push and pull force | 30 N |
| Orbital load | 380 kg/m |
| Sound insulation coefficient | 45 DB |
| Panel material |
Melamine Board |
Sound proof partitions components
Tracks: Made of good quality anodized aluminium 6063-T5 materials, hanging the movable walls panels with wheels.
Wheels/Rollers: It is the carrier for the sound proof partitions, let the panels move more flexibly. Pulley bearing is more than 1600 KGS.
Connectors: The sound proof partitions made of anodized aluminium 6063-T5 aluminum tracks, “L”, “T”, “＋”types are available.
Rubber/vinyl seal: Made of Nitrile Butadiene Rubber(NBR+PVC),durable and perfect for sound insulation, wear-resistant.
Rock Wool: Density of 50kg/m3, help us reduce the noise and heat.
Handle: Operate the retractable being up and down.
Retractable mechanism: Control the movement of the top and bottom seal to form a excellent sound insulation performance.
Magnetic Strip: Ferrite plastic magnetic material will be used in between aluminum profiles to enhance acoustic performance of the sound proof partitions.
MDF board: 9 mm thickness, density of 760kg/m3, absorbent thickness expansion rate is less than 15%. Formaldehyde emission is 34mg/100g.
Sound proof partitions advantages
Sound proof partitions are specified where functional space delineation is an integral element within the sound proof partitions project.
Due to their flexibility and cost effectiveness they allow large rooms to be conveniently sub-divided to maximize space utilization.
Principle applications include office interiors, meeting rooms, sports and leisure facilities, schools, colleges, churches, conference and function suites, exhibition centers, banks and restaurants.
Sound proof partitions technicals
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | ||
| Track system | Single or twin point | ||
| Panel thickness | 65mm | 85mm | 100mm |
| Panel height | Up to 3500mm | Up to 5200mm | Up to 17000mm |
| Max height | 3500mm | 5200mm | 17000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | ||
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire retardant | as request | ||
| Retractable seals | have | ||
| Adjustable panels | Manual, with supplied operating handle | ||
| Pass doors | Single door or double door as request | ||
| Sound insulation | 32dB | 40dB | 50dB |
| Weight | Approx 22-35kg/sqm | Approx 25-40kg/sqm | Approx30-48kg/sqm |
| Finish Material |
Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) |
||
