Industrial Mobile Sliding Operable Sound Proof Partitions / Folding Room Dividers
Product Details:
| Place of Origin: | Guangdong |
| Brand Name: | BANGE |
| Certification: | ISO9001 |
| Model Number: | 85 mm sound proof partitions |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | US Dollars 80 - 120 per square meters |
| Packaging Details: | Carton package, MDF batten on four section sides , foam board on both front face. |
| Delivery Time: | 15-20 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Open Style: | Sliding | Product Name: | Sound Proof Partitions |
|---|---|---|---|
| Feature: | Sound Proofing | Size: | 85 Mm |
| Color: | Accept Customized | Application: | Banquet Hall,office,function Room |
| Panel Width: | 500 Mm--1230 Mm | Door Material: | Melamine Board |
| Surface: | Melamine,leather,fabric,plywood | Position: | Interior |
| Width: | 85 Mm(3 1/4 Inch) | ||
| High Light: | sounproof folding partition,movable soundproof partition |
||
Product Description
Industrial Mobile Sliding Folding Partition Walls Operable Sound Proof Partitions
Features & Benefits
Movable, top hung system without the need for a floor track.
Retractable top and bottom seals ensure effortless movement of panels.
Combines elegance with robust construction.
Concealed or exposed panel edge profiles.
Numerous panel stacking options for complete flexibility.
Sealed for life roller assemblies provide smooth and silent movement.
Various levels of sound reduction.
Specifications of Sound Proof Partitions System
|
Model |
BG-65 series |
BG-85 series |
BG-100 series |
BG-high series |
|
Suspension system |
Aluminum hanging |
Aluminum hanging |
Aluminum hanging |
Steel hanging |
|
Basic thickness |
65mm |
85mm |
100mm |
100mm |
|
Total thickness |
65/75/85/95mm |
80/90/100/110mm |
100/120/130mm |
100/120/130mm |
|
Max height |
Up to 3800mm |
Up to 4500mm |
Up to 6500mm |
Up to 12000mm |
|
Width |
600-1230mm |
600-1230mm |
800-1230mm |
800-1230mm |
|
Floor/ceiling sealing strength |
Telescopic aluminum tube with rubber strip |
|||
|
Side walls sealing strength |
Double seal tape |
|||
|
Sound insulation level |
26dB-30dB |
28dB-34dB |
32-40dB |
32-48dB |
|
Panel structure |
Aluminum frame with wooden keel |
Aluminum frame with steel keel |
||
|
Panel density |
22-28kg/sqm. |
24-32kg/sqm. |
32-50kg/sqm. |
/ |
|
Surface material |
Melamine laminate/fabric/PU leather/wallpaper/veneer/customized |
|||
The application of Sound Proof Partitions
Nowadays, the modern trend in buildings needs more flexibility and convenience to use the space of their rooms. Most of the building designers like to prepare open plan space, sound proof effect, and easy to operate. The solution of the designers need is the Sound Proof Partition.
Sound Proof Partitions are available in a several choices of plywood,MDF with melamine, fabric, fabric with foam, PU, and wall covering finishesassurance that the aesthetic integrity of your space will be preserved.
Sound Proof Partitions can quickly divide a big area into several separate rooms for group activities, family gatherings, church suppers, classes, etc.
Sound Proof Partitions also come in varying degrees of acoustical control to suit specific needs.
Converting meeting room space has never been so easy and flexible.
Sound Proof Partitions provide a virtually limitless number of room configurations.
More room configurations mean optimum space use and more convention and meeting income from the same square footage. There will be more guest bookings and greater return on investment.
