Panel Height 4m Classroom Sound Proof Room Dividers Top Hanging System Movable Track Roller
Product Details:
| Place of Origin: | China,Guangzhou |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | Series 85 mm sound proof partition |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | 95 /129 dollar per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Finished: | Melamine | Certificate: | ISO9001 |
|---|---|---|---|
| Height: | 6 M | Thickness: | 85 Mm |
| Width: | 500-1200 Mm | Service: | OEM Service |
| Open Style: | Sliding | Position: | Commercial |
| Application: | Classroom,office | Product Name: | Sound Proof Partitions |
| High Light: | movable sound proof partitions,movable soundproof partition |
||
Product Description
Movable Track Roller Classroom Dividers Sound Proof Partition
Technical information:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Max height | 4000 mm | 6000 mm | 18000 mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9 mm | 9 mm | 12 mm |
| Pass doors | Single door or Double door | ||
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
|
Finish Material |
Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Specification:
Sound proof partition offer reliable solutions for your space division requirements. We have been devoted to the act or process of creating quality, functional areas for residential, commercial and industrial applications.
The strength of our company is based upon a combination of our 10 years experience, representing established manufacturers committed to quality, an attention to detail, and an installation crew bent on completing the job right and on schedule.
Staying current with the latest architectural and engineering trends as well as a hands on approach from conception to completion has also helped keep clients coming back for more. Give us a call and talk to our professionals about folding walls,movable walls,operable walls and flexible space design.
Surface :
The standard colour for the track profile of the folding wall and the jamb profiles is white and the panels edge profiles are natural anodized.
There is a wide variety of panel surface treatments.
As a special solution it is possible to install a glass opening in the center of the panel. The opening can cover the whole panel, the bottom or the top.
Feature:
1. No need floor suspension: There is no track on the floor, just install the track on the ceiling;
2. Stable and safe: It is stable and reliable after being cut off, and it is not easy to swing;
3. Insulation and energy conservation: excellent insulation performance, according to different seating rates, the large space is divided into small spaces to reduce the air conditioning power consumption;
4. Beautiful and generous: any surface decoration, can be combined with the indoor decoration effect;
5. Retractable and flexible: The partitions move freely, promote flexibility, and one person can complete the entire process of partitioning;
Advantage:
Long-term use: with more economy and higher decorative, beautiful and safe, will not scratch the skin.
Cost savings: installation does not affect the construction of smallpox and the ground.
Various forms: optional with a variety of occasions partition wall, can be customized according to customer requirements.
Easy combination: in the re-assembly can make full use of building materials.
Material environmental protection: selection of high-quality melamine particleboard, sound insulation and sealing a good variety of accessories a variety of options.
Structure:
When the operable folding wall system is supported at the ceiling it runs along an adjustable aluminum upper track that is equipped with bearings inside of carriages. This enables the walls height to be adjusted by 15 mm.
The carriages are installed on every second wall panel and are located at the center of the panel. Because the wall hangs from the ceiling, it is important for the installation of the wall that the wall is attached to something solid (i.e. concrete ceiling, steel structure, wood beam etc).
In the case that the folding wall is supported by the ground, an aluminum track is installed on the floor where the carriages move the wall and at the top there is a guiding track. The height is also adjustable by 15 mm.
