Operable Wood Folding Movable Partition Walls for Office Soundproof
Product Details:
| Place of Origin: | China,Guangzhou |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | Series 85 mm movable partition wall |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | 119 / 128 dollar per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Color: | Multi Color | Panel Type: | Melamine |
|---|---|---|---|
| Application: | Conference Hall, Office | Service: | OEM Service |
| Metal Type: | Aluminium | Thickness: | 85 Mm |
| Open Style: | Folding | Position: | Commercial |
| Function: | Soundproof | Width: | 500-1200 Mm |
| Height: | 6 M | ||
| High Light: | movable walls on wheels,acoustic movable walls |
||
Product Description
Operable Wood Folding Office Soundproof Movable Partition Wall
Description:
Sliding Room Dividers divide a room in minutes with single thickness 65 mm sliding panels. No heavy beams or bracing in the ceiling is required. The lightweight top guide track can even mount directly to a suspended ceiling. The floor track is easily removable so the floor is clear when the room divider is not in use.
Movable Wall has excellent acoustical properties. When it comes to sound insulation this Movable Acoustic Wall is the obvious choice, its sound insulation ranges from 37-53 decibels.
Movable Wall Panels runs smoothly along its tracks on ball-bearing trolleys and is very easy to operate, it is rigid, robust and has safety features that assist in its operation.
Feature:
1. No need floor suspension: There is no track on the floor, just install the track on the ceiling;
2. Stable and safe: It is stable and reliable after being cut off, and it is not easy to swing;
3. Insulation and energy conservation: excellent insulation performance, according to different seating rates, the large space is divided into small spaces to reduce the air conditioning power consumption;
4.High-efficiency fire prevention: The use of high-efficiency fireproof materials, good fireproof performance;
5. Beautiful and generous: any surface decoration, can be combined with the indoor decoration effect;
6. Retractable and flexible: The partitions move freely, promote flexibility, and one person can complete the entire process of partitioning;
Fix sliding partition wall:
Hold the screen with one hand, and put the handle in the hexagonal steel at the 1100mm side of the screen side material. Hold the handle and turn it clockwise by 180 degrees (or continuously shake).The telescopic seal inside the screen will pop up to fix the screen.
Insert the handle into the groove on the side of the screen, and pull the handle upwards to open the expansion screen inside the screen to fix the screen. After putting the entire group of screens, check if the screen is straight? Whether it is on the same plane as the rail, if not straight, retract the upper and lower expansion seals to adjust until the screen is straight.
Technical information:
| Panel Suspension | Top hanging system without the need for a floor track. |
| Panel Width | Each panel 600mm-1200mm. |
| Track | Aluminum Or Steel Track |
| Roller on panel | Single or Double Roller |
| Panel Frames | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
| Top and bottom seals | Top and bottom pressure retractable seals ensure effortless moved and locked. |
| Module | 700mm - 1200mm maximum. |
| Panel stacking | Numerous panel stacking options for complete flexibility. |
| Panel Surface | MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc. |
| Finishes | Satin anodized or polyester powder coating to all exposed aluminium components available in a wide range of colour as standard. |
Sound insulation:
The sound insulation coefficient of partitions comes from many directions, not only in the partition wall itself, but also in other links, as follows:
1. Horizontal sound insulation
In order to achieve the best sound insulation, two layers of sound-absorbing rubber structure are used. Using the jack principle, the double rubber strip is pressed against the ceiling track and floor to provide a high stability of the active partition.
2. Corner sound insulation
The use of specially shaped rubber-like corner elements solves the technical problems of handling corner seals; at the same time, superior stability and sound insulation are achieved.
3. Vertical sound insulation
All the soundproof walls are made of highly elastic vertical contact side, concave and convex groove close fitting principle, to ensure the best closure and sound insulation.
4. Skeleton
In view of the hanging structure of the wall plate, it can be freely shaken, and the metal hoop elements between the wall plates are closely combined, effectively blocking the sound transmission. Panels can be replaced as needed for interior design without damaging the entire panel.
Advantage:
Long-term use: with more economy and higher decorative, beautiful and safe, will not scratch the skin.
Cost savings: installation does not affect the construction of smallpox and the ground.
Various forms: optional with a variety of occasions partition wall, can be customized according to customer requirements.
Easy combination: in the re-assembly can make full use of building materials.
Material environmental protection: selection of high-quality melamine particleboard, sound insulation and sealing a good variety of accessories a variety of options.
