Wooden Mobile Folding Partition Doors Movable Walls For Restaurant
Product Details:
Place of Origin: | Guangzhou, China |
Brand Name: | EBUNGE |
Certification: | ISO 9001 |
Model Number: | Model 65 folding partitions movable walls |
Payment & Shipping Terms:
Minimum Order Quantity: | NO MOQ, small quantity welcome |
---|---|
Price: | $82-88 per square meter |
Packaging Details: | Paper carton, outside with wooden box |
Delivery Time: | 7-15 days |
Payment Terms: | T/T, MoneyGram |
Supply Ability: | 50000 square meters per month |
Detail Information |
|||
Product Name: | Folding Partitions Movable Walls | Panel Thick: | 65 Mm |
---|---|---|---|
Max Height: | 4 M | Carrier Over Load: | 225-1300 Kg |
Application: | Five Star Hotel Partition | Finishing: | Melamine |
High Light: | Restaurant Folding Partition Doors,Movable Folding Partition Doors,Melamine Movable Partition Walls |
Product Description
Five Star Hotel Soundproof Folding Partition Walls With Aluminum Tracks
Folding Partitions Movable Walls Detail
The folding partitions movable walls is a system of individual solid or glazed panels that can moved independently from each other which when fitted together end to end form a continuous flat, faceted or curved wall. Operable wall panels are designed to be easily manoeuvred and operated.
They are top hung from either a surface or recessed mounted head track and no floor track is required. Various head track formations are possible to provide different stacking options.
Each folding partitions movable walls panel is provided with interlocking seals to each vertical profile, retractable top and bottom seals are either manually or electrically operated.
The seals pressure close against the ceiling channel and floor to provide a continuous seal. Individual panels can incorporate single or double door sets and junction panels to form various configurations.
Final closure of the folding partition wall can be by a telescopic panel, extending wall jamb or full height door.
Series | BG65 | BG85 | BG100 |
Panel suspension | Top hung only | Top hung only | Top hung only |
Track system | Single or twin point | Single or twin point | Single or twin point |
Panel thickness | 65mm | 80mm / 85mm | 100mm |
Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
Max height | 4000mm | 6000mm | 18000mm |
Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
Face material | 9mm | 9mm / 12mm | 12mm |
Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) |
Folding Partitions Movable Walls Features
1. Individual panels that can be stored away for maximum space usage.
2. Operable top and bottom seals for effortless operation.
3. Aluminum frame construction for enhanced acoustics.
4. The system offers various levels of sound reduction
5. Unique track and carrier system ensuring quiet and easy operation.
6. Numerous panel stacking options for complete flexibility.
7. Top hung and no floor track.
8. Extensive range of surface finishes can be availabled.
