Office Building Flexible Movable Sliding Sound Proof Partition

Office Building Flexible Movable Sliding Sound Proof Partition

Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO 9001
Model Number: 85 mm acoustic movable walls

Payment & Shipping Terms:

Minimum Order Quantity: NO MOQ, small quantity welcome
Price: $82-88 per square meter
Packaging Details: Paper carton, outside with wooden box
Delivery Time: 7-15 days
Payment Terms: T/T, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Sound Proof Partition Application: Office Partition
Thickness: 85 Mm Function: Divide The Space
Color: White Packing: Wooden Box
High Light:

4000mm Height Sound Proof Partition

,

Multidirectional Movable Sound Proof Partition

Product Description

Office Building Flexible Movable Sliding Sound Proof Partition

Office Building Flexible Movable Sliding Sound Proof Partition




Sound proof partition detail



Suspension System



Suspension Tracks: Each sound proof partition panel is suspended on one 4-wheel ball-bearing trolley or two multi-directional polymer trolleys. The individual panel is adjustable in height without the opening of the ceiling or panel.



Carriers: Trolley system as required for configuration type, size, and weight of partition and for easy operation; with ball-bearing wheels.



Multidirectional Carriers: Capable of negotiating 90-degree L, T, and X intersections without track switches.



Track Intersections, Switches, and Accessories: As required for type of operation, storage, track configuration, and layout indicated for operable panel partitions, and compatible with partition assembly specified. Fabricate sound proof partition track intersections and switches from steel or aluminum.



Aluminum Finish: Manufacturer's standard, factory-applied, decorative finish, unless otherwise indicated.



Installation



Install sound proof partition and accessories after other finishing operations, including painting, have been completed.



Install sound proof partition panels from marked packages in numbered sequence indicated on Shop Drawings.



Broken, cracked, chipped, deformed, or unmatched panels are not acceptable.



General: Comply with operable panel partition manufacturer's written installation instructions.





Adjusting



Adjust sound proof partitions to operate smoothly, without warping or binding.



Lubricate hardware and other moving parts.



Adjust sound proof partitions to operate smoothly and easily, without binding or warping.



Check and readjust operating hardware.



Confirm that latches and locks engage accurately and securely without forcing or binding.

Office Building Flexible Movable Sliding Sound Proof Partition 0





Technical Information


Series Model 65 Model 85 Model 100
Panel suspension Top hung only Top hung only Top hung only
Panel thickness 65 mm 85 mm 100 mm
Max height 4000 mm 6000 mm 8000 mm
Panel width 600-1230 mm 600-1230 mm 600-1230 mm
Based board thickness 9 mm 9 mm 9 mm
Pass doors selection Single Door or Double Door
Sound insulation 20 – 32 db 28 – 36 db 32 – 50 db
Finish Material Plywood / MDF /Laminate / Melamine / Gypsum
Board / Fabric / Insulation / Fireproof /Wall Paper /Vinyl /Painting /etc,(Customized)





How to maintain the sound proof partitions



First of all: cleaning of sound proof partition



In hotel rooms, multi-function halls, meeting rooms, large banquets and other areas, such sound proof partitions are widely used. It is inevitable that some food, drinks, etc. will be spilled on the sound proof partitions. If the surface is soiled, It is necessary to use professional cleaning, you can use some alkaline water and alkaline washing liquid to clean the dirt on the partition. It is also possible to use industrial sodium hydroxide to lightly coat the decorative surface of the movable sound proof partition, and wash it with water after half an hour. At the same time, you can apply some vinegar to the oily area, wipe it evenly on the surface of the movable partition, let him absorb it slowly, and then wash it with clean water.

Second: Sound proof partition maintenance



At the same time of sound proof partition, pay attention to keep away from some flammable dangerous goods as much as possible, because some partition surfaces are made of soft packages, hard packages, etc., which are prone to safety hazards when encountering open flames. In the process of using the movable sound proof partition, if the top hanging wheel is damaged, the telescopic component fails or cannot be pushed, the parts are loose, etc., try not to dismantle it privately. Professional maintenance personnel should be notified to solve the problem. At the same time, we will visit from time to time. Do maintenance, let you use it at ease, let your space be separated as you want, and divided as you want.
