OEM Acoustic Partition Wall 85 MM Demountable Separation Shutter Removable Sliding Wooden Panels

OEM Acoustic Partition Wall 85 MM Demountable Separation Shutter Removable Sliding Wooden Panels

Product Details:

Place of Origin: Guangdong, China
Brand Name: EBUNGE
Model Number: 85 MM

Payment & Shipping Terms:

Minimum Order Quantity: 1 square meter
Price: Negotiable
Packaging Details: Carton paper packing ,MDF Batten cover all over the corner
Delivery Time: 7-28 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Acoustic Partition Wall Material: MDF With Melamine
Color: Customized Service: ODM & OEM
Finish: Melamine;fabric;leather Package: Standard Wooden Case
Frame Material: Aluminum Alloy Profile Max Height: 6000 MM
Thickness: 85 MM Acoustic Rate: 25 - 36 Db
Condition: New
High Light:

acoustic operable partitions

,

movable acoustic partition walls

Product Description

85 MM Demountable Separation Shutter Removable Sliding Wooden Panels Acoustic Wall Partitions

Product description:

Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 80mm / 85mm 100mm
Panel height Up to 4000mm Up to 6000mm Up to 18000mm
Max height 4000mm 6000mm 18000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame Aluminum frame Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire safety Optional Class I or O Optional Class I or O Optional Class I or O
Vertical profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles
Retractable seals Aluminum black with
double rubber seals
Aluminum black with double rubber seals Aluminum black with double rubber seals
Operation of seals Manual, with supplied
operating handle
Manual, with supplied operating handle Manual, with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass doors Single open in panel or
double open in two panel
Single open in panel or double open in two panel Single open in panel or double open in two panel
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx30-48kg/sq M
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)



Acoustic operable walls and movable partitions are used extensively in large rooms to partition the space for maximize space utilization, revenue potential and sound control. Acoustic walls are quick to operate and are available in a range of acoustic ratings from 30db - 49db. Sound attenuation is achieved by modern manufacturing methods and the unique panel construction that consists of an aluminum frame, particle board cladding and multiple acoustic infills.



OEM Acoustic Partition Wall 85 MM Demountable Separation Shutter Removable Sliding Wooden Panels 0

Operation

When the operable seals are retracted, panels glide effortlessly and quietly along the unique aluminum overhead ceiling track system (no need for floor guide).

When moving a wall panel, there is a 20-25mm gap between the top of the panel and the underside of the head track and there is a similar gap between the bottom of the panel and the floor.

Once a panel is positioned, acoustic integrity is maintained along the top and bottom of the panel by extending pressure seals. The pressure seals are extended and retracted by a single 180° turn of a removable operating handle.

Final closure of the wall is achwared by extending a telescopic sleeve on the last panel. This action simultaneously extends the top and bottom seals.

Features

1. Top hung without the need for a floor track.

2. Smooth and easy operation. Panels are moved individually.

3. Panels may be parked away from opening.

4. Widely used in hotel banquet hall, exhibition hall, schools, restaurants, hospitals, conference, office meeting room and others.

OEM Acoustic Partition Wall 85 MM Demountable Separation Shutter Removable Sliding Wooden Panels 1

FAQ

1.Q: Are you a manufacturer or trading company?

A: We are a  real manufacturer, and this is our address: No.39-2, Nanwei Road, Hailong street, Longxi Avenue, Liwan District, Guangdong Province, China.



2. Q: What is the price of the movable wall?

A: Our mobile wall system is customized, the cost is calculated by area, the thickness of different walls and the price of different finishes are different. Therefore, we need you to provide us detailed dimensions such as height, width and finish requirements. If possible, we also need your layout drawings.



3. Q: Is the movable partition acoustic (soundproof)?

A: Yes, our movable wall system is soundproof. We have different acoustic material fillings and various sound absorbing panels to achieve different acoustic ratings. For the 65 series we can reach 45db, for the 80 type we can reach 48db, the 85 type can reach 50db, for the 100 type we can reach 50db.



4.Q: How to install an active partition? Is it difficult to complete?

A: It is not difficult to install our active partitions. Our active partition is a hanging rail type moving wall that does not require any ground track. Therefore the hanging rail structure will be very important. We have very detailed drawings and videos showing how to install, so your employees just need to follow them step by step.



5.Q: Do you provide sample?

A: Yes, and the sample is free, you just pay the express delivery fee is ok.



6.Q: What is your payment terms?

A : 30% - 50% of total amount by T/T as deposit when confirmed the order and balance paid by T/T before loading container, or irrevocable L/C at sight.



7. Q : What is your warranty ? What do we do in case of problems?

A : 3 years quality warranty is provided, including frame unfading nor peel-off, hardware and accessories working properly under correct operation.In case of our quality problem, we will provide replacement by international courier. Immediate delivery of replacement parts with available in stock, and if not stocking, the time should be depending on material ordering time which is normally 10- 15 days.
