Conference Rooms Meeting Rooms Sliding Partition Walls For Office / Operable Panels Movable Doors
Product Details:
Place of Origin: | Guangdong, China |
Brand Name: | EBUNGE |
Model Number: | 85 MM |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 square meter |
---|---|
Price: | Negotiable |
Packaging Details: | Carton paper packing ,MDF Batten cover all over the corner |
Delivery Time: | 7-28 days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 10000 square meters per month |
Detail Information |
|||
Product Name: | Sliding Partition Walls | Material: | MDF With Melamine |
---|---|---|---|
Color: | Customized | Service: | ODM & OEM |
Finish: | Melamine;fabric;leather | Package: | Standard Wooden Case |
Frame Material: | Aluminum Alloy Profile | Max Height: | 6000 MM |
Thickness: | 85 MM | Acoustic Rate: | 25 - 36 Db |
Transport: | Sea Transportation | ||
High Light: | sliding folding partition,sound proof sliding partitions |
Product Description
Operable Panels Movable Doors Conference Rooms Meeting Rooms Sliding Partition Walls For Office
Product description:
Series | BG65 | BG85 | BG100 |
Panel suspension | Top hung only | Top hung only | Top hung only |
Track system | Single or twin point | Single or twin point | Single or twin point |
Panel thickness | 65mm | 80mm / 85mm | 100mm |
Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
Max height | 4000mm | 6000mm | 18000mm |
Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
Face material | 9mm | 9mm / 12mm | 12mm |
Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) |
Nowadays, the effective division of space sometimes requires utmost flexibility. Whether the requirement is to divide a teaching area, temporarily partition a conference suite, or simply create extra rooms out of a large space, the answer is movable walls.
Alongside Bunge movable walls, the products also include hinged partitions and concertina olding partitions along with a range of glass movable walls and industrial doors.
Bunge provides unrivalled experience in the design and manufacture of space utilisation products.
We have four types of movable wall, 65 type, 85 type, 100 type and 125 ultra-high type.
You can choose the right movable wall upon the height and soundproof requirement as following,
65 type, max height: 4000mm(160 inch), soundproof: 22-28db
85 type, max height: 6000mm(240 inch), soundproof: 25-36db
100type, max height: 9000mm(350 inch), soundprood: 30-50db
125 ultra-high type, max height: 17000mm(670 inch), soundproof: 40-55db
FAQ
1.Q: Are you a manufacturer or trading company?
A: We are a famanufacturer, and this is our address: No.39-2, Nanwei Road, Hailong street, Longxi Avenue, Liwan District, Guangdong Province, China.
2. Q: What is the price of the movable wall?
A: Our mobile wall system is customized, the cost is calculated by area, the thickness of different walls and the price of different finishes are different. Therefore, we need you to provide us detailed dimensions such as height, width and finish requirements. If possible, we also need your layout drawings.
3. Q: Is the movable partition acoustic (soundproof)?
A: Yes, our movable wall system is soundproof. We have different acoustic material fillings and various sound absorbing panels to achieve different acoustic ratings. For the 65 series we can reach 45db, for the 80 type we can reach 48db, the 85 type can reach 50db, for the 100 type we can reach 50db.
4.Q: How to install an active partition? Is it difficult to complete?
A: It is not difficult to install our active partitions. Our active partition is a hanging rail type moving wall that does not require any ground track. Therefore the hanging rail structure will be very important. We have very detailed drawings and videos showing how to install, so your employees just need to follow them step by step.
5.Q: Do you provide sample?
A: Yes, and the sample is free, you just pay the express delivery fee is ok.
6.Q: What is your payment terms?
A : 30% - 50% of total amount by T/T as deposit when confirmed the order and balance paid by T/T before loading container, or irrevocable L/C at sight.
7. Q : What is your warranty ? What do we do in case of problems?
A : 3 years quality warranty is provided, including frame unfading nor peel-off, hardware and accessories working properly under correct operation.In case of our quality problem, we will provide replacement by international courier. Immediate delivery of replacement parts with available in stock, and if not stocking, the time should be depending on material ordering time which is normally 10- 15 days.
Very welcome to visit our Web and contact us!
Send us a question below to get a movable wall catolog and special discounts!
