Top hung Acoustic Partition Wall Aluminium Movable Mirror Glass Wall Panel Folding Mirrored Room Divider Screen

Certification
Good quality Movable Partition Walls for sales
Good quality Movable Partition Walls for sales
Customer Reviews
We had installed the partition wall - it worked out well and our customer is happy. So we would like to thank you for delivering high quality goods an

—— Frank

I am so glad to cooperate with Bunge. Their products with good quality and pretty competitive price. My customers like it very much.

—— Grace

We have a lot of business with Bunge since 2011 ,I hope we have more orders and they continue to give our best service and quality.

—— Roger

Bunge is very serious and responsible supplier , partition walls have good quality and high sound proof .

—— Charles

I'm Online Chat Now

Top hung Acoustic Partition Wall Aluminium Movable Mirror Glass Wall Panel Folding Mirrored Room Divider Screen

China Top hung Acoustic Partition Wall Aluminium Movable Mirror Glass Wall Panel Folding Mirrored Room Divider Screen supplier
Top hung Acoustic Partition Wall Aluminium Movable Mirror Glass Wall Panel Folding Mirrored Room Divider Screen supplier Top hung Acoustic Partition Wall Aluminium Movable Mirror Glass Wall Panel Folding Mirrored Room Divider Screen supplier Top hung Acoustic Partition Wall Aluminium Movable Mirror Glass Wall Panel Folding Mirrored Room Divider Screen supplier Top hung Acoustic Partition Wall Aluminium Movable Mirror Glass Wall Panel Folding Mirrored Room Divider Screen supplier

Large Image :  Top hung Acoustic Partition Wall Aluminium Movable Mirror Glass Wall Panel Folding Mirrored Room Divider Screen

Product Details:

Place of Origin: Guangzhou,China
Brand Name: EBUNGE
Model Number: Series 65 mm Acoustic partition wall

Payment & Shipping Terms:

Minimum Order Quantity: No MOQ
Price: 60-101 USD per square meter
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face.
Delivery Time: Shipped in 10 days after payment, based on the quantity.
Payment Terms: T/T
Supply Ability: 5000 square meters per month
Contact Now
Detailed Product Description
Product Name: Acoustic Partition Wall Material: Aluminium Frame And Mdf Board
Height: Less Then 4 M Width: 500-1200 Mm
Thickness: 65mm Function: Space Divide,sound Proof
Style: Modern Style Warranty: 3-5 Years

Acoustic partition wall aluminium china movable mirror glass wall panel folding mirrored room divider screen

Soundproofing details:

BUNGE satisfies the most stringent requirements a user may demand from a movable wall.



Movable Wall has excellent acoustical properties. When it comes to sound insulation this Movable Acoustic Wall is the obvious choice, its sound insulation ranges from 32-53 decibels.



The Movable Wall Panels runs smoothly along its tracks on ball-bearing trolley and is very easy to operate, it is rigid, robust and has safety features that assist in its operation.



It can benefit from a specially made steel self-supporting frame structure of which can achieve heights of more than 15 meters. Operated by a specialist scissor jack mechanism that ensures the greatest possible stability and the highest degree of soundproofing.

Top hung Acoustic Partition Wall Aluminium Movable Mirror Glass Wall Panel Folding Mirrored Room Divider Screen

Technical parameters:

Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 80mm / 85mm 100mm
Panel height Up to 4000mm Up to 6000mm Up to 18000mm
Max height 4000mm 6000mm 18000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame Aluminum frame Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire safety Optional Class I or O Optional Class I or O Optional Class I or O
Vertical profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles
Retractable seals Aluminum black with
double rubber seals
Aluminum black with double rubber seals Aluminum black with double rubber seals
Operation of seals Manual, with supplied
operating handle
Manual, with supplied operating handle Manual, with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass doors Single open in panel or
double open in two panel
Single open in panel or double open in two panel Single open in panel or double open in two panel
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx30-48kg/sq M
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wallpaper, Vinyl, Painting, etc. (Customized)

Top hung Acoustic Partition Wall Aluminium Movable Mirror Glass Wall Panel Folding Mirrored Room Divider Screen



Advantage:

Hinged pair panels for quick and easy operation.

Robust aluminum frame construction for demanding environments.

Room divider wide range of surface finishes.

Partial and fully operating panels available.

Partition divider just only top hung supported without floor track.

Top hung Acoustic Partition Wall Aluminium Movable Mirror Glass Wall Panel Folding Mirrored Room Divider Screen



Introduction:

The sliding partition wall is our individual panel partition system offering an acoustic insulation rating of up to 53 dB.
Ideally suited for high specification applications due to the sheer flexibility, numerous stacking arrangements available and the impressive acoustic qualities this system offers.

The panels are operated by means of an internal scissor-jack mechanism and move effortlessly along an aluminum head track, when closed they form a securely fixed wall.

The movable wall system is a high quality bespoke movable wall system to suit timber panels up to 150 kilograms in weight, there are multiple options for Door types, parking areas, and track layouts. Each door is a top hung straight sliding panel which sits in line with the other doors these panels can be moved into a parking area when the wall needs to be opened, pivot panels can be fixed or converted into sliding doors. Timber movable walls can be created to suit any space within reason.
