Sound Insulation Office Wall Partition Floor To Ceiling Hanging System
Product Details:
| Place of Origin: | China,Guangzhou |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | Series 65 mm sound proof partitions |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | 85 /131 dollar per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Finished: | Melamine,fabric,leather | Height: | Less Than 4 M |
|---|---|---|---|
| Thickness: | 65 Mm | Width: | 800-1200 Mm |
| Application: | Office,conference Room | Product Name: | Sound Proof Partitions |
| Service: | OEM Service | Open Style: | Sliding And Folding |
| Function: | Divide Space | Color: | Multi Color |
| High Light: | sounproof folding partition,movable sound proof partitions |
||
Product Description
Sound Insulation Floor to Ceiling Hanging System Sliding Folding Office Sound Proof Wall Partition
Technical information:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Max height | 4000 mm | 6000 mm | 18000 mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9 mm | 9 mm | 12 mm |
| Pass doors | Single door or Double door | ||
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
|
Finish Material |
Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Specification:
The movable partition wall is characterized by high sound insulation, fire prevention, mobility, and easy operation. It is extremely suitable for the use of space spaces in star hotel ballrooms, high-grade restaurant rooms, and high-level office conference rooms.
Soundproof partition wall feature:
1. Floor less suspension: There is no track on the floor, just install the track on the ceiling;
2.Stable and safe: It is stable and reliable after being cut off, and it is not easy to swing;
3.Compartments environmental protection: the compartment effect is good, the maximum sound insulation coefficient up to 50db;
4.Insulation and energy saving: excellent heat insulation performance, according to different occupancy rates, divide the large rating into small spaces to reduce air conditioning power consumption;
Structure:
The operable wall structure is composed of aluminum profiles, sheets of treated particleboard or MDF and insulation. The combined structure forms a panel that has a total thickness of 85mm and depending on the insulation material ensures a soundproof resistance .
When the operable folding wall system is supported at the ceiling it runs along an adjustable aluminum upper track that is equipped with bearings inside of carriages. This enables the walls height to be adjusted by 15 mm.
The carriages are installed on every second wall panel and are located at the center of the panel. Because the wall hangs from the ceiling, it is important for the installation of the wall that the wall is attached to something solid (concrete ceiling, steel structure, wood beam etc.).
Surface:
1. The partition wall of the movable partition series consists of glass, melamine board, fire board, color steel plate, gypsum board and other decorative materials.
2.The heart is made of aluminum alloy frame and steel with fire, moisture, noise, environmental protection, non-deformation and other functions, in the hotel partition layout, color and surface decoration, etc. to maintain the hotel after the partition is simple and exquisite, durable and flexible use Diversified spaces and very stylish hotel interior style after partition.
Installation:
1. When the partition is hung on the track, escape exit tracks can be removed without rebuilding the crane.
2. For the escape exit track must be a special bracket track connection.
3. When installing the track, perform the construction according to the accurate data of the adjustment during the measurement.
Trak system:
1. Remember that the rails are loose enough on all brackets. Guaranteed track pause time.
2. Tighten all rail connections and adjust the rail height correctly. The rail mounting direction must also be straight and horizontal.
3. In the installation of track facilities, sound insulation and mineral wool are necessary for installation.
4. There are "L", "T" and "Ten" spurs for the track. There are left and right points for the connection of the steering. It is generally not recommended to use the "10" spur. L and T are trimmed to their corresponding size, and their position is indicated by a numerical marker.
Our service:
A full professional design service.
Survey and installation guide.
Using top quality materials and components.
A fully experienced work team.
Maintenance contracts to ensure your valuable asset remains in full work order.
