Product Details:

Place of Origin: China,Guangzhou
Brand Name: BUNGE
Certification: ISO9001
Model Number: Series 65 mm sound proof partitions

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: 85 /131 dollar per square meter
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face.
Delivery Time: Shipped in 10 days after payment, based on the quantity.
Payment Terms: D/A, D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability: 5000 square meters per month
Get Best Price Contact Now

Detail Information

Finished: Melamine,leather,plywood Certificate: ISO9001
Height: Less Than 4 M Thickness: 65 Mm
Width: 500-1300 Mm Application: Restaurant,banquet Hall,hotel
Product Name: Sound Proof Partitions Color: Multi Color
Open Style: Sliding Position: Commercial
High Light:

sounproof folding partition

,

movable soundproof partition

Product Description

Decorative Material Sound Insulation Sliding Partition Wall Panel 500mm Width

Decorative Material Sound Insulation Sliding Wall Soundproof Movable Restaurant Partition



Technical information:



Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Panel thickness 65 mm 85 mm 100 mm
Max height 4000 mm 6000 mm 18000 mm
Panel width 500-1200 mm 500-1200 mm 500-1200 mm
Face material 9 mm 9 mm 12 mm
Pass doors Single door or Double door
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw



Finish Material

Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)



Specification:



Soundproof partition wall also call can move partition, move partition, orbit partition. Mobile partition has the characteristics of easy installation, reusable, industrial production, fire protection and environmental protection.


Soundproof wall partition brings great convenience to people's work, such as active screen, you are in need of it can be folded in the side, make two Spaces temporary joint and appear larger, convenient small temporary department meetings, some product USES the landless rail system, have can completely reach the effect as solid wall.


Soundproof partition wall feature:



1. Floor less suspension: There is no track on the floor, just install the track on the ceiling;


2.Stable and safe: It is stable and reliable after being cut off, and it is not easy to swing;


3.Compartments environmental protection: the compartment effect is good, the maximum sound insulation coefficient up to 50db;



4.Insulation and energy saving: excellent heat insulation performance, according to different occupancy rates, divide the large rating into small spaces to reduce air conditioning power consumption;



5.High-efficiency fire prevention: The production of high-efficiency fireproof materials, and good fireproof performance;



Decorative Material Sound Insulation Sliding Partition Wall Panel 500mm Width 0



Track system:



For single or paired panels up to 250kg. One 4-wheeled carrier is provided per panel, each wheel is consists of molded polymer tires on hardened steel ball bearings.Resilient mounted body for quite operation and load distribution.special for center stacking option. Usual dimension from the ceiling to the structure is 200mm.



For directional panel up to 225kg. Two carriers are provided per panel. Each carrier has two horizontal counter-rotating wheels that roll (not slide) in the track. Each wheel has precision ground bearings, encased with POM for quiet operation. Carriers easily negotiate square or angled corners without switches. Usual dimension from the ceiling to the structure is 200mm.



Application:



Its high performance per dollar value and the easiest in-field operation makes it very suitable for Hotel, banquet hall, conference room ,ballroom, muti-function hall, restaurant,classroom,office,religion,dance studio ,shopping arcades and many other place where seek for space divide with good soundproof performance .



Decorative Material Sound Insulation Sliding Partition Wall Panel 500mm Width 1



Soundproof movable partition details:



Movable partition in the daily use should pay attention to maintenance, such as failure can not be removed to repair, but also can not damage the telescopic components inside, if you encounter problems, you should contact the manufacturer for repair or replacement. Secondly, it should be used normally when using the partition, and it can not be used irregularly. It is easy to cause malfunction or damage if it is not used.



Our service:



We design and manufacture value for many products with one year's warranty on all the outstanding ranges illustrated in this brochure.
They offer a complete service package covering site surveys, CAD technical drawings, and quotation presentation. Emphasis is placed on quality assurance backed by a comprehensive after sales service.
