2000mm Height Sound Proof Movable Sliding Partition Walls For Conference Hall
Product Details:
| Place of Origin: | Guangzhou,China |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | 65 mm sliding partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | 20 square meters |
|---|---|
| Price: | US $76-138 per square meters |
| Packaging Details: | Paper carton inside,and wooden boxes for outside. |
| Delivery Time: | 15-25 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Thickness: | 65 Mm(2 9/16 Inch) | Application: | Banquet Hall,hotel |
|---|---|---|---|
| Feature: | Sound Proofing | Color: | Accept Customized |
| Payment Terms: | T/T | Product Name: | Sliding Partition Walls |
| High Light: | sliding folding partition,sound proof sliding partitions |
||
Product Description
Soundproof Movable Sliding Tracks Rails Partition Walls for Conference Hall
Sliding partition walls details
- Material: MDF, glass fiber, aluminum sound proof
- Surface treatment: veneer, melamine
- Coefficient: 30-60db
- Width: 800-1230mm
- Height 2000-4200mm
- Color: multi-color design decorative partition wall
- Fireproof: Yes
- Environment: E1 level
Sliding partition walls operation:
When moving a sliding partition walls panel there is a 22.5-25 mm gap between the top of the panel and the underside of the head track, there is a similar gap between the bottom of the panel and the floor.
Once a sliding partition walls panel is positioned, acoustic integrity is maintained along the top and bottom of the panel by extending pressure seals.
The pressure seals are extended and retracted by a single 180°turn of a removable operating handle.
Final closure of the wall is achieved by extending a telescopic sleeve on the last panel. This action simultaneously extends the top and bottom seals.
Folding room partitions technical details:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Max height | 4000 mm | 6000 mm | 18000 mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9 mm | 9 mm | 12 mm |
| Pass doors | Single door or Double door | ||
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
|
Finish Material |
Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Sliding partition walls features:
1> No track is required on the floor. Sliding partition walls does not affect the whole style of decoration.
2> Sliding partition wall has soundproofing and heat insulation function. It can quickly and easily separate the space.
3> Sliding partition wall is hanging on the aluminum alloy rails by multi-directional wheels.
4> The sliding room partition wall panel is made of aluminum frame, high quality sound insulation cotton and finishing board.
5> Different finishes are available to meet the different requirements of customers.
6> There are soundproof rubber around each partition door piece, which help isolate the sound.
7> We can add a single door or double doors to the conference hall partitions.
Conference hall sliding partition walls has been widely used in hotels, banquet hall, office buildings, multi-purpose hall, conference rooms, exhibition hall, financing institutions, hospitals, factories and other occasions.
