MDF Moveable Operable Partition Wall Panels For Conference Room / Exhibition Hall
Product Details:
Place of Origin: | Guangzhou,China |
Brand Name: | BUNGE |
Certification: | ISO9001 |
Model Number: | 65 mm sound proof partitions |
Payment & Shipping Terms:
Minimum Order Quantity: | 20 square meters |
---|---|
Price: | $80-130 per square meter. |
Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
Delivery Time: | 7-10 days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 5000 square meters per month. |
Detail Information |
|||
Color: | Accept Customized | Thickness: | 65 Mm(2 9/16 Inch) |
---|---|---|---|
Height: | 2000/13000 Mm | Panel Width: | 500 Mm--1220 Mm |
Product Name: | Sound Proof Partitions | Feature: | Sound Proofing |
High Light: | sounproof folding partition,movable soundproof partition |
Product Description
MDF Moveable Partitions Operable Soundproof Partition Wall Panels for Conference Room
Sound proof partitions advantages:
Bunge sound proof partition, to achieve all-round, multi-space perspective flexible separation, can be repeated folding, space reuse, energy saving, simple and generous, fully demonstrated demonstrate the art of interior space of the space.
High quality. The use of environmentally friendly materials, formaldehyde emission in line with national standards {1.5mg / L}, The material has strong, durable (abrasion resistance), fire protection, anti-deformation, anti-flammability, anti-aging, fastness, etc.anti-aging;
High noise. Fully meet the five-star hotel noise standards, the highest sound insulation up to 55db (more than 30% stronger than ordinary indoor wall insulation);
Wide range of applications. Movable sound proof partition screen used in the star hotel Banquet Hall, Conference Room, Exhibition Hall, Office, Multi-Function Hall and other large space need to be divided into places;
Can be customized on demand. Customized according to the different needs of customers, such as cut off the model, surface decoration and collection methods such as design, to meet the different site decoration style.
Sound proof partitions operation:
When moving a wall panel there is a 22.5-25 mm gap between the top of the panel and the underside of the head track, there is a similar gap between the bottom of the panel and the floor.
Once a panel is positioned, acoustic integrity is maintained along the top and bottom of the panel by extending pressure seals.
The pressure seals are extended and retracted by a single 180°turn of a removable operating handle.
Final closure of the wall is achieved by extending a telescopic sleeve on the last panel. This action simultaneously extends the top and bottom seals.
Technical information:
Series | BG65 | BG85 | BG100 |
Panel suspension | Top hung only | Top hung only | Top hung only |
Track system | Single or twin point | Single or twin point | Single or twin point |
Panel thickness | 65mm | 80mm / 85mm | 100mm |
Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
Max height | 4000mm | 6000mm | 18000mm |
Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
Face material | 9mm | 9mm / 12mm | 12mm |
Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) |
