Soundproof Material Wooden Foldable Partition Wall / Aluminium Frame Sliding Room Dividers
Product Details:
| Place of Origin: | China,Guangzhou |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | Series 65 mm foldable partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | 92 / 136 dollar per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Color: | Multi Color | Finished: | Melamine |
|---|---|---|---|
| Structure: | Aluminium Frame +MDF Board | Height: | 4 M |
| Thickness: | 65 Mm | Door Material: | Aluminium Alloy |
| Application: | Conference Room | ||
| High Light: | soundproof folding partition,folding room partitions |
||
Product Description
Soundproof Material Sliding Room Divider Wooden Foldable Partition Wall
Specification:
Foldable partition wall is made of high quality anodized aluminum frame with environmentally composite materials.The panels move on a ceiling track with no requirement of floor guides or rails,and they have a standard thickness of 65 mm,80 mm and 100 mm,and a width up to 1230 mm.Maximum height can reach 13meter tall.
Feature:
1) Movable partition board is modernized decoration style. It can separate the space speedy and conveniently, it is usually used in banquet hall, school, hotel etc.It has sound insulation and heat insulation and fireproof function.
2) Our wall partition is made of high quality anodized aluminum frame with composite materials.The panel Type 80 has a standard thickness of 65mm and a width up to1219mm. Maximum height can reach 4500mm tall.
3) Its vertical seal,together with the horizontal top and bottom retractable seals providing excellent acoustic insulation property of maximum STC-45.
4) The partitions may be finished with a selection from our standard MDF or plywood board, or with optional fabric, leather, melamine, high pressure laminate, murals, or other custom surfaces. And pass through door or glass window can be applied additionally.Property of maximum STC-45.
5) The partitions may be finished with a selection from our standard MDF or plywood board, or with optional fabric, leather, melamine, high pressure laminate, murals, or other custom surfaces. And pass through door or glass window can be applied additionally.
Advantage:
Long-term use: with more economy and higher decorative, beautiful and safe, will not scratch the skin.
Cost savings: installation does not affect the construction of smallpox and the ground.
Various forms: optional with a variety of occasions partition wall, can be customized according to customer requirements.
Easy combination: in the re-assembly can make full use of building materials.
Material environmental protection: selection of high-quality melamine particleboard, sound insulation and sealing a good variety of accessories a variety of options.
Technical information:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 65mm | 80mm / 85mm | 100mm |
| Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
| Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
| Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
| Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
| Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
We can offer:
A full professional design service.
Survey and installation guide.
Using top quality materials and components.
A fully experienced work team.
Maintenance contracts to ensure your valuable asset remains in full work order.
