White Wooden Acoustic Partition Wall For Conference Room / Sound Proof Movable Wall Dividers
Product Details:
| Place of Origin: | Guangdong |
| Brand Name: | BANGE |
| Certification: | ISO9001 |
| Model Number: | 85 mm wooden partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | US Dollars 80 - 120 per square meters |
| Packaging Details: | Carton package, MDF batten on four section sides , foam board on both front face. |
| Delivery Time: | 15-20 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Open Style: | Sliding | Product Name: | Wooden Partition Walls |
|---|---|---|---|
| Feature: | Sound Proofing | Size: | 85 Mm |
| Color: | Accept Customized | Application: | Office,hotel,conference Room |
| Panel Width: | 500 Mm--1230 Mm | Door Material: | Melamine Board |
| Surface: | Melamine,leather,fabric,plywood | Position: | Interior |
| Width: | 85 Mm(3 1/4 Inch) | ||
| High Light: | acoustic operable wall,movable acoustic partition walls |
||
Product Description
Conference Room Soundproof Movable Wall Dividers Acoustic Wooden Partition Walls
The details about wooden partition walls
Wooden partition wall is also called movable partition wall. It can separate the space into several small spaces or turn several small spaces into big space ccording to your different need. Morever, it’s flexible sliding combination bring you a special experience.
1. Eight characters and functions:
(1) hang track on the ceiling, not the floor;
(2) heat insulation and fireproof
(3) stable and safe
(4) energy-efficientcy
(5) elegant appearance
(6) collection convenient
(7) widely used in different places
2. Usage:
Type 65 is suitable to use at 2m-3.5m height space.
Type 85 is suitable to use at 2m-6m height space.
Type 100 is suitable to use at 3m-9m height space.
3. Each panel load-bearing weight: 225kgs/ 450kgs/ 650kgs
4. Sound insulation coefficient:
Type 65 highest sound insulation coefficient can be reach is 36db.
Type 85 the highest sound insulation coefficient can be reach is 50db.
Type 100 the highest sound insulation coefficient can be reach is 53db.
The specification of wooden partitions
Mainly structure is generally composed of aluminium track, rollers, sealing strips, aluminium frames, reference surface materials, sound insulation materials, transmission rods, and sealant strips.
When moving the wooden partition walls there is a 22.5-25mm gap between the top of the panel and the
underside of the head track, there is a similar gap between the bottom of the panel and the floor.
Once a panel is positioned, acoustic integrity is maintained along the top and bottom of the panel by extending pressure seals.
The pressure seals are extended and retracted by a single 180°turn of a removable operating handle.Final closure of the wall is achieved by extending a telescopic sleeve on the last panel. This action simultaneously extends the top and bottom seals.
There are wide of range face finishes are available:melamine faced MDF or Plywood, fabric, carpet, fabric, artificial, leather,wood veneer, high pressure laminate,Formica ,acoustic panel,white boad ect., Panels can also be supplied unfinished for field decoration,Standard frame color is clear anodized aluminum,custom powder coating colors are available.
BUNGE wooden partition walls works with Architects,designer,developers,contractores and owners in design product selection,decorative finishes,project management and after-sales warranty services as her one-stop solution business service.
| Panel Suspension: | Top hunge system without the need for a floor track. |
| Panel Width: | Each panel 600mm-1200mm. |
| Track: | Aluminum OR Steel Track |
| Rollor on panel | Single or double roller |
| Panel Frames: | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
| Top&bottm seals: | Top and bottom pressure retractable seals ensure effortless moved and locked. |
| Module: | 700mm - 1200mm maximum. |
| Panel stacking: | Numerous panel stacking options for complete flexibility. |
| Panel face: | MDF,Plywood,woven fabric.Leather,Natural wood veneer, Melamine,Wood moldings, etc |
| Finishes: | Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard. |
FAQ:
1.How can you guarantee the quality?
We have a modern management system. Take strict selection for upstream suppliers to insure the basic material to be good quality. And we pay more attention to production technology and staff training, so that the defective rate is less than 1% of each products, save cost at the production line. When the productions are ready, they would be sent to the package workshop, put in carton with foam between each panel to avoid the friction and damage.
2.Can you offer sample?
Yes, we can offer standard samples for free, and customization is available.
3.Do you accept customization?
Yes, we can support our clients with OEM, so that it can be easier to open the local market and build a long-term partnership between us.
4.How long is the lead time?
Normally 10-25 days upon receiving the deposit, base on the quantity 1,500 SQM
5.Can you assist for installation?
Yes, we can arrange to assist in installation if needed.
6.Do you have CE certificate?
Yes, we do. We have shipped many goods to European countries.
7.What are the factors of influencing the NRC?
Perforation rate, gap between the wall and panel, the density and thickness of the glass wool, etc. All these factors will effect NRC.
8.What's the difference between normal panel and acoustic panel?
Acoustic panel also called soundproof panel which is designed according to the law of soundproofing. There are mainly three functions of acoustic panel. Sound absorbing, sound diffusing and sound insulation, with respect to a specified sound source and receptor: increasing the distance between source and receiver, using acoustic panel to reflect or absorb the energy of the sound waves, using damping structures such as acoustic panel, or using active antinoise sound generators.
