4m Height Operable Acoustic Sliding Partition Walls MDF Board + Aluminium Material
Product Details:
| Place of Origin: | China,Guangzhou |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | Series 85 mm sliding room partition |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | 97 /132 dollar per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Application: | Office,conference Room | Height: | 4 M |
|---|---|---|---|
| Material: | MDF Board+Aluminium | Thickness: | 65 Mm |
| Color: | Multi Color | Open Style: | Folding |
| Position: | Commercial | Width: | 500-1200 Mm |
| Service: | OEM Service | ||
| High Light: | acoustic sliding partition,sound proof sliding partitions |
||
Product Description
Operable Movable Acoustic Sliding Folding Partition Walls
Description:
The partition wall is a good consideration of the propagation of sound waves, greatly improving the soundproofing of the partition. Partition models 65 type (65mm thick), 85 type (85mm thick), 100 type (100mm thick), ultra-high type, partition reference plane material gypsum board, fiber board, glass magnesium board, color steel plate, sound-absorbing board.
A variety of panels, such as melamine panels, are available for selection. The structure and frame are made of 6063-T6 reinforced aluminum alloy. The installation height is less than 10,000mm.
The soundproofing performance of the partition is significant. After laboratory tests, the air sound insulation can reach up to RW=53dB. The panel material and internal soundproof materials used in the fire-proof partition are all flame-retardant materials.
Technical information:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Max height | 4000 mm | 6000 mm | 18000 mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9 mm | 9 mm | 12 mm |
| Pass doors | Single door or Double door | ||
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
|
Finish Material |
Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Application:
The operable wall series is used wherever room space needs to be fully utilized. Hotels, conference centers, educational establishments, offices, training areas, etc. can all benefit from the flexibility of Dividers operable walls.
Feature:
Individual panels that can be stored away for maximum space utilization.
Operable top and bottom seals for effortless operation.
Isolated aluminium frame construction for enhanced acoustics.
High performance multiple in fill's for maximum sound attenuation.
Unique track and carrier system ensuring quiet and easy operation.
Numerous panel stacking options for complete flexibility.
No floor track ensuring obstruction free threshold.
Three panel sizes to accommodate a wide range of acoustic requirements .
Parking movable wall:
1. If there is a door in the door, first turn the square hole on both sides of the door to rotate 180 degrees, loosen the upper and lower seals through the transmission wheel, and then close the door in the door;
2, open the last screen of the telescopic aluminum plate and the upper and lower seals;
3. Retract the telescopic aluminum plate of the last screen so that its distance can at least turn the distance of the screen, generally about 140 mm;
4. Push the screen to the position of the screen in the direction of the track.
5. After each group of screens is collected in the same way, press each two screens tightly to minimize the distance between the screens and the screens. If necessary, you can open the up and down motion seals of the last screen that is housed at the hidden plate so that it presses against the rails and the ground. This will prevent others from easily pulling the screen out.
Acoustic performance:
Our top Hung acoustic operable walls were designed specifically with the office refurbishment sector in mind. With sound attentions available from 37dB RW to 53 dB RW, there is no acoustic issue between rooms that the Top Hung Operable Wall cannot cater for.
Sound reduction dB ratings are often quoted from laboratory test results which are misleading in respect of final performance values. They are merely useful for initial specification purposes. Independent on-site tests as carried out by partners are recommended as in-situ results will differ from laboratory test certification and are therefore the only true guide to achievable sound attenuation.
