Foldable Movable Sliding Partition Walls Floor to Ceiling 85mm Thickness
Product Details:
| Place of Origin: | China,Guangzhou |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | Series 85 mm folding partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | 98 / 127 dollar per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Service: | OEM Service | Metal Type: | Aluminium |
|---|---|---|---|
| Height: | 6 M | Color: | Multi Color |
| Open Style: | Folding | Application: | Office,conference Room |
| Function: | Soundproof | Thickness: | 85 Mm |
| Door Material: | MDF Board | Panel Type: | Melamine,acoustic Fabric |
| High Light: | acoustic folding partition,soundproof folding partition |
||
Product Description
Folding Partition Walls,Office Partitions,Sliding Room Partition
Description:
Bunge movable partition walls is made of high quality anodized aluminum frame with environmentally composite materials.The panels move on a ceiling track with no requirement of floor guides or rails,and they have a standard thickness of 65 mm,80 mm and 100 mm,and a width up to 1230 mm.Maximum height can reach 13 meter tall.
The movable partition is a kind of operable wall that can divide a large space into a small space or a small space into a large space at any time according to needs and has a general wall function. It can serve as a multi-purpose room with multiple functions.
The movable partition has the characteristics of easy installation, reliability, industrial production, fire prevention, and environmental protection.
Feature:
No floor rails: floor without track, just install the track on the ceiling.
Stable and safe: stable and reliable after the partition, easy to swing.
Sound insulation: sound insulation effect, the maximum sound insulation up to 53 dB.
Insulation energy saving: excellent insulation performance, according to different seating rate, the large space is divided into small space to reduce air conditioning power consumption.
Efficient fire: the use of highly efficient fire prevention materials, fire performance is good.
Nice: the surface of any decoration, with a unified indoor decorative effect.
Retractable and flexible: the partition retractable, flexible, a person can complete the whole process of cutting off.
Collection convenience: the closing board, the partition can be hidden in the special storage expensive, does not affect the overall appearance.
Sound insulation:
The sound insulation coefficient of partitions comes from many directions, not only in the partition wall itself, but also in other links, as follows:
1. Horizontal sound insulation
In order to achieve the best sound insulation, two layers of sound-absorbing rubber structure are used. Using the jack principle, the double rubber strip is pressed against the ceiling track and floor to provide a high stability of the active partition.
2. Corner sound insulation
The use of specially shaped rubber-like corner elements solves the technical problems of handling corner seals; at the same time, superior stability and sound insulation are achieved.
3. Vertical sound insulation
All the soundproof walls are made of highly elastic vertical contact side, concave and convex groove close fitting principle, to ensure the best closure and sound insulation.
4. Skeleton
In view of the hanging structure of the wall plate, it can be freely shaken, and the metal hoop elements between the wall plates are closely combined, effectively blocking the sound transmission. Panels can be replaced as needed for interior design without damaging the entire panel.
Technical information:
| TYPE | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | ||
| Track system | Single or twin point | ||
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Panel height | Up to 4000mm,heights greater than 3000mm refer to our technical dept. | Up to 6000mm, heights greater than 6000mm refer to our technical dept. Inset passing doors above 2400mm. Full height passing door up to 3000mm high document ‘M’ disabled doors optional. | |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width |
500 - 1200mm 1' 5/8" -- 4' |
500 - 1200mm 1' 5/8" -- 4' |
500 - 1200mm 1' 5/8" -- 4' |
| Frame | Aluminum | Aluminum | Aluminum |
| Surface material | 9mm | 9mm | 12mm |
| Fire safety | Optional class I | Optional class I | Optional class I |
| Vertical profiles | Aluminum, anodized with sealing profiles, painter optional | Aluminum, anodized with sealing profiles, painter optional | Aluminum, anodized with sealing profiles, painter optional |
| Retractable seals | Aluminum, black with double rubber seals | Aluminum, black with double rubber seals | Aluminum, black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle | ||
| Locking | Optional lock to passing doors | ||
| Passing doors | Single open in one panel or double open in two panel | ||
| Sound insulation | 32-38dB Rw | 36-45dB Rw | 42-55dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx 30-48kg/sq M |
We can offer:
A full professional design service.
Survey and installation guide.
Using top quality materials and components.
A fully experienced work team.
Maintenance contracts to ensure your valuable asset remains in full work order.
Supply you prompt and competitive price.
Supply you strict quality-compliance and punctual delivery.
Organize the shipment for you.
Reliable after service: timely service and efficient response.
