• Folding Partition Walls , Acoustic Movable Partition For Banquet Wedding Facility
Folding Partition Walls , Acoustic Movable Partition For Banquet Wedding Facility

Folding Partition Walls , Acoustic Movable Partition For Banquet Wedding Facility

Product Details:

Place of Origin: China
Brand Name: BUNGE
Model Number: Type65

Payment & Shipping Terms:

Minimum Order Quantity: 10 Square Meters
Price: US $ 100 - 300 / Square Meter
Packaging Details: Carton package , MDF batten on four section sides , foam board on both front face
Delivery Time: 10 working days after received your payment
Payment Terms: T/T
Supply Ability: 5,000 Square Meters per Month
Get Best Price Contact Now

Detail Information

Thickness Mm: 65mm Weight Kg/m2: 28 / 43
Max Panel Height: 4000mm Surface: Veneer , Leather , MDF , Melamin , Fabric
Frame: Aluminum Panel Construction / Seal: Operable
High Light:

soundproof folding partition

,

folding room partitions

Product Description





Folding Partition Walls , Acoustic Movable Partition For Banquet Wedding Facility





Specifications :



Technical Parameter for Partition Panel

Panel Width

500 - 1230mm

Panel height

2000 - 4000mm

Sound proof

32 - 36db

Operation

Manual

Frame

Aluminum

Vertical profile

Anodised aluminum profiles with integrated magnetic strip and sealing edges on the inside

Finish options

Fabric, veneer, HPL melamine, vinyl, carpet, customers own material, Bare finish

Base options

Plywood, Gypsum, steel, MDF

Max width

Unlimited

Panel weight

28 - 40 kg / sq

Pass door selection

door

Single or double door

Seals

Top

Manual

bottom

Manual





Track :



The tracks are made from extruded 6063 – T6 anodized aluminum . The track housing shall utilize grooves and interlocking steel pins for positive alignment of adjacent track sections , and shall be reinforced overhead by drop rod brackets . Aluminum track housing shall include an integral nut slot to accept a hardened square nut for attaching each drop rod bracket to the top of the track .



Trolley



BUNGE Centre / Side / Remote stacking system with a Two wheeled nylon trolley made with the base Material of POM 45 tempered steel shall be used as per approved stacking method .





Acoustic insulation Material



Rockwool sound absorption glass fiber shall be used.





Magnetic Strip



Ferrite plastic magnetic material will be used in between aluminum profiles to enhance acoustic performance of the wall.





Stacking :

The panels will be stacked as per the agreed method and in accordance with the architetural plan. Centre stacking arrangement will be utilized for the subject project.





Applications :



Our products (Movable Partitions) are widely used in the hotel banquet halls , meeting rooms , exhibition halls , conference rooms , International Convention Centers , KTVs , upscale restaurants , office buildings , schools , hospitals and others .



Bunge aluminium movable partition wall and operable partition wall acoustic movable partition for convention & exhibition centre ( used office room dividers , wood partition , movable wall , restaurant partitions , soundproof folding partition , moveable partition , wall partition , living room partition wall, sandwich panel price, accordion wall , economic partition walls , folding wall, foldable partition wall, folding partition wall , movable sound proof partition , removable wall partition , folding partition , removable partition , partition, partition wall, room divider , room dividing partition , office partition , folding partition wall panel , folding wall panel , folding wall systems )
