Decorative Office Folding Sliding Partition Movable Soundproof Walls For Restaurant
Product Details:
| Place of Origin: | Guangzhou, China |
| Brand Name: | EBUNGE |
| Certification: | ISO 9001 |
| Model Number: | BG85 movable soundproof walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | No MOQ, small quantity welcome |
|---|---|
| Price: | US Dollars 82-100 per square meter |
| Packaging Details: | Paper carton, outside with wooden box |
| Delivery Time: | 7-30 days |
| Payment Terms: | T/T, Western Union, MoneyGram, D/P, D/A, L/C |
| Supply Ability: | 10000 square meters per month |
|
Detail Information |
|||
| Product Name: | Movable Soundproof Walls | Usage: | Interior |
|---|---|---|---|
| Surface: | Melamine+Fabric | Color: | Black |
| Application: | Restaurant Movable Soundproof Walls | Thickness: | 85 Mm |
| High Light: | Movable Office Folding Sliding Partition,Soundproof Folding Sliding Partition |
||
Product Description
Decorative Office Folding Sliding Partition Movable Soundproof Walls For Restaurant
Different Types of Movable Soundproof Walls
Some movable walls are permanent. These are retracted in site when they are not needed. Others are temporary and are removed, relocated and reinstalled in different locations when needed.
Movable walls come in two main configurations: modular or unitised. Modular walls require on-site assembly and are delivered in sections. Unitised walls are delivered in a semi-assembled state and can be quicker to instal.
Electrically-operated walls or room dividers are typically more expensive than manually operated walls. If frequent moves are required and the ceiling can support the electric system, this option may be preferred. Manually operated walls might be used in spaces where the ceiling and wall supports would be unable to carry the weight of an electric system.
Vertical folding walls slide into compartments in ceiling spaces when not in use. Since they retract into the ceiling, they require no floor space.
Vertical folding walls are typically electrically operated and require less structural support than their horizontal counterparts. Horizontal movable walls are more commonly used, and may be available with greater customisation options including glass, wood and many other finishes. Some even integrate technology, so walls can serve as smart surfaces to support business functions.
Technical Information
|
TYPE
|
BG65 | BG85 | BG100 |
|
Panel suspension
|
Top hung only
|
||
|
Track system
|
Single or twin point
|
||
|
Panel thickness
|
65MM
|
85MM
|
100MM
|
|
Panel height
|
Up to 4000mm,Heights greater than 3000mm refer to our Technical Dept
|
Up to 6000mm,Heights greater than 6000mm refer to our Technical Dept.inset Pass doors above 2400mm.Full Height pass door up to 3000mm high Document 'M'disabled doors-optional
|
|
|
Max height
|
4000mm with heavy duty track
|
6000mm with heavy duty track
|
18000mm with heavy duty track or steel track
|
|
Panel width
|
600-1200mm
|
||
|
Frame construction
|
Aluminium
|
Aluminium
|
Aluminium/steel
|
|
Face material
|
9mm/12mm
|
9mm/12mm
|
9mm/12mm/15mm
|
|
Fire safety
|
optional Class I or O
|
||
|
Vertical profiles
|
Aluminium,anodised with sealing profiles,painted-optional
|
Aluminium,anodised with sealing profiles,painted-optional
|
Aluminium,anodised with sealing profiles,painted-optional
|
|
Retractable seals
|
Aluminium,black with double rubber seals
|
Aluminium,black with double rubber seals
|
Aluminium,black with double rubber seals
|
|
Operation of seals
|
Manual,with supplied operating handle
|
||
|
Locking
|
Optional lock to pass doors
|
||
|
Pass Doors
|
Single open in oanel or double open in two panel
|
||
|
Sound insulation
|
41,43,48dB Rw
|
43,48,51,53dB Rw
|
48,51,53,58dB Rw
|
|
Weight
|
Approx 33-40kg/sq M
|
Approx 43-50kg/sq M
|
Approx 63-70kg/sq M
|
Movable Soundproof Walls Features
1. Floor supported on a bottom roller track system with guide channel at top.
2. Alternatively, top hung with/without floor track
3. Floor track features concealed fixings
4. Face operated espagnolette bolts lock wall securely in position
5. Continuous contact sweep seals minimise sound transfer
6. Single wing or bi-parting configurations
7. Leading element is full height pass door
8. Optional vision panels
9. Parking centrally or to side of line of track
10. Panel finishes include vinyl, veneer, melamine laminate, a magnetic dry wipe enamelled writing surface or paint
