Five Star Hotel Soundproof Folding Partition Walls With Aluminum Tracks

Five Star Hotel Soundproof Folding Partition Walls With Aluminum Tracks

Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO 9001
Model Number: Model 65 folding partition walls

Payment & Shipping Terms:

Minimum Order Quantity: NO MOQ, small quantity welcome
Price: $82-88 per square meter
Packaging Details: Paper carton, outside with wooden box
Delivery Time: 7-15 days
Payment Terms: T/T, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Folding Partition Walls Track Material: Aluminum Alloy
Frame Material: Aluminum Alloy Carrier Over Load: 225-1300 Kg
Application: Five Star Hotel Partition Finishing: Melamine
High Light:

Soundproof Folding Partition Walls

,

1300kg Load Folding Partition Walls

,

Aluminum Alloy Folding Partition Walls

Product Description

Five Star Hotel Soundproof Folding Partition Walls With Aluminum Tracks





Folding Partition Wall Detail


Folding partition walls come in two main configurations: modular or unitised. Modular walls require on-site assembly and are delivered in sections. Unitised walls are delivered in a semi-assembled state and can be quicker to instal.


Electrically-operated folding partition walls or room dividers are typically more expensive than manually operated walls. If frequent moves are required and the ceiling can support the electric system, this option may be preferred. Manually operated walls might be used in spaces where the ceiling and wall supports would be unable to carry the weight of an electric system.


Folding partition walls slide into compartments in ceiling spaces when not in use. Since they retract into the ceiling, they require no floor space.



Folding partition walls are typically electrically operated and require less structural support than their horizontal counterparts. Horizontal movable walls are more commonly used, and may be available with greater customisation options including glass, wood and many other finishes. Some even integrate technology, so walls can serve as smart surfaces to support business functions.





Technical Information

Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 80mm / 85mm 100mm
Panel height Up to 4000mm Up to 6000mm Up to 18000mm
Max height 4000mm 6000mm 18000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame Aluminum frame Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire safety Optional Class I or O Optional Class I or O Optional Class I or O
Vertical profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles
Retractable seals Aluminum black with
double rubber seals
Aluminum black with double rubber seals Aluminum black with double rubber seals
Operation of seals Manual, with supplied
operating handle
Manual, with supplied operating handle Manual, with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass doors Single open in panel or
double open in two panel
Single open in panel or double open in two panel Single open in panel or double open in two panel
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx30-48kg/sq M
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)

Five Star Hotel Soundproof Folding Partition Walls With Aluminum Tracks 0





Folding Partition Wlls Features



Sound rating from 22dB to 55 dB.


No floor track – only overhead tracks.


Maximum height of up to 15 m.


Allow flexible room layout.


Individual panel neatly parked on one side or one niche.


Segment a meeting room or conference facility.


Allow rooms to be completely private.
