Office Space Divider Sliding Hanging Movable Partition Walls For Conference Hall

Office Space Divider Sliding Hanging Movable Partition Walls For Conference Hall

Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO 9001
Model Number: Model 100 hanging movable partition

Payment & Shipping Terms:

Minimum Order Quantity: NO MOQ, small quantity welcome
Price: $82-88 per square meter
Packaging Details: Paper carton, outside with wooden box
Delivery Time: 7-15 days
Payment Terms: T/T, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Hanging Movable Partition Panel Thickness: 100 Mm
Height: 2-15 Meters Feature: Folding
Application: Conference Hall Partition Style: Office Space Divider
High Light:

Conference Hall Movable Partition Walls

,

4000mm height Movable Partition Walls

,

Sound Insulation Movable Partition Walls

Product Description

Office Space Divider Sliding Hanging Movable Partition Walls For Conference Hall

Office Space Divider Sliding Hanging Movable Partition Walls For Conference Hall





Hanging Movable Partition Sound Insulation Conditions



The sound insulation coefficient of hanging movable partition comes from multiple directions, not only in the partition wall itself, but also in other links, such as the door, window, ceiling, wall at different project site. It means that the noise also can be pass through the windeo, door, ceiling or wall.



In order to achieve a better sound insulation effect, two layers of sound insulation rubber are used. BUNGE uses the principle of a jack to tightly press the double-layer rubber strips on the ceiling track and the floor to provide a highly stable hanging movable partition. For corner sound insulation, special molded rubber corner components are used to solve the technical problems of corner sealing; at the same time, stability and sound insulation effects are also achieved. Vertical sound insulation, all sound insulation walls are made of highly elastic vertical stickers.



Technical Information

Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 80mm / 85mm 100mm
Panel height Up to 4000mm Up to 6000mm Up to 18000mm
Max height 4000mm 6000mm 18000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame Aluminum frame Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire safety Optional Class I or O Optional Class I or O Optional Class I or O
Vertical profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles
Retractable seals Aluminum black with
double rubber seals
Aluminum black with double rubber seals Aluminum black with double rubber seals
Operation of seals Manual, with supplied
operating handle
Manual, with supplied operating handle Manual, with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass doors Single open in panel or
double open in two panel
Single open in panel or double open in two panel Single open in panel or double open in two panel
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx30-48kg/sq M
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)

Office Space Divider Sliding Hanging Movable Partition Walls For Conference Hall 0





Hanging Movable Partition Features



1. Environmental protection



The hanging movable partition will be made of aluminum alloy and wood materials. Compared with the traditional wall, the installation and construction are simple, the cost is low, and it can be repeatedly disassembled and assembled. Small damage can be repaired at any time, without large-scale replacement, and the scrap aluminum alloy can also be recycled. In addition, the hanging movable partition has the function of heat preservation and heat insulation, which reduces the power consumption.



2. Sound insulation



The hanging movable partition may not be as effective as the traditional Chinese partition wall, but the effect can be improved through technological development and the use of sound insulation cotton and other scientific materials. After the hotel management and construction are completed, more technical optimization of sound insulation is needed to reflect the advantages of the hotel partition. When necessary, hanging movable partitions can provide better sound insulation effects than traditional walls.



3. Flexible design



The design feature of hanging movable partition is destined to be flexible. In order to enable the hotel to develop a more diversified business model and improve the hotel's quality, movable partitions are a decoration direction that cannot be ignored in the hotel decoration design. The flexible and diverse hotel layout is more conducive to the development trend of the hotel.
