Office Space Divider Sliding Hanging Movable Partition Walls For Conference Hall
Product Details:
| Place of Origin: | Guangzhou, China |
| Brand Name: | EBUNGE |
| Certification: | ISO 9001 |
| Model Number: | Model 100 hanging movable partition |
Payment & Shipping Terms:
| Minimum Order Quantity: | NO MOQ, small quantity welcome |
|---|---|
| Price: | $82-88 per square meter |
| Packaging Details: | Paper carton, outside with wooden box |
| Delivery Time: | 7-15 days |
| Payment Terms: | T/T, MoneyGram |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Product Name: | Hanging Movable Partition | Panel Thickness: | 100 Mm |
|---|---|---|---|
| Height: | 2-15 Meters | Feature: | Folding |
| Application: | Conference Hall Partition | Style: | Office Space Divider |
| High Light: | Conference Hall Movable Partition Walls,4000mm height Movable Partition Walls,Sound Insulation Movable Partition Walls |
||
Product Description
Office Space Divider Sliding Hanging Movable Partition Walls For Conference Hall
Hanging Movable Partition Sound Insulation Conditions
The sound insulation coefficient of hanging movable partition comes from multiple directions, not only in the partition wall itself, but also in other links, such as the door, window, ceiling, wall at different project site. It means that the noise also can be pass through the windeo, door, ceiling or wall.
In order to achieve a better sound insulation effect, two layers of sound insulation rubber are used. BUNGE uses the principle of a jack to tightly press the double-layer rubber strips on the ceiling track and the floor to provide a highly stable hanging movable partition. For corner sound insulation, special molded rubber corner components are used to solve the technical problems of corner sealing; at the same time, stability and sound insulation effects are also achieved. Vertical sound insulation, all sound insulation walls are made of highly elastic vertical stickers.
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 65mm | 80mm / 85mm | 100mm |
| Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
| Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
| Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
| Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
| Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Hanging Movable Partition Features
1. Environmental protection
The hanging movable partition will be made of aluminum alloy and wood materials. Compared with the traditional wall, the installation and construction are simple, the cost is low, and it can be repeatedly disassembled and assembled. Small damage can be repaired at any time, without large-scale replacement, and the scrap aluminum alloy can also be recycled. In addition, the hanging movable partition has the function of heat preservation and heat insulation, which reduces the power consumption.
2. Sound insulation
The hanging movable partition may not be as effective as the traditional Chinese partition wall, but the effect can be improved through technological development and the use of sound insulation cotton and other scientific materials. After the hotel management and construction are completed, more technical optimization of sound insulation is needed to reflect the advantages of the hotel partition. When necessary, hanging movable partitions can provide better sound insulation effects than traditional walls.
3. Flexible design
The design feature of hanging movable partition is destined to be flexible. In order to enable the hotel to develop a more diversified business model and improve the hotel's quality, movable partitions are a decoration direction that cannot be ignored in the hotel decoration design. The flexible and diverse hotel layout is more conducive to the development trend of the hotel.
