Office Temporary Divider Aluminum Frame Sliding Folding Movable Wall Partitions

Office Temporary Divider Aluminum Frame Sliding Folding Movable Wall Partitions

Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO 9001
Model Number: Model 85 moveable wall partitions

Payment & Shipping Terms:

Minimum Order Quantity: NO MOQ, small quantity welcome
Price: $82-88 per square meter
Packaging Details: Paper carton, outside with wooden box
Delivery Time: 7-15 days
Payment Terms: T/T, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Moveable Wall Partitions Panel Thickness: 85 Mm
Panel Width: 800-1200 Mm Feature: Folding
Application: Office Wall Partitions Style: Temporary Divider
High Light:

36dB Movable Wall Partitions

,

85mm Thickness Movable Wall Partitions

,

MDF Movable Wall Partitions

Product Description

Office Temporary Divider Aluminum Frame Sliding Folding Movable Wall Partitions

Office Temporary Divider Aluminum Frame Sliding Folding Moveable Wall Partitions





Moveable Wall Partitions Operation



1. How to fix multi-directional moveable wall partitions?



Hold the screen with one hand and insert the handle into the hexagonal steel at 1100mm on the side of the screen. Grab the handle and turn it clockwise by 180 degrees. The retractable seal inside the screen will pop out to fix the screen and insert the handle. The groove on the side of the hotel partition, pull the handle upwards to open the retractable seal fixed screen inside the screen, the hotel partition screen put the whole set of screens and check whether the screen is straight and whether it is on the same plane as the rail, if not straight Then retract the upper and lower retractable seals to adjust until the screen is straight.



2. How to open the partition screen of moveable wall partitions?



All operations should be gentle and safe. Stand facing the screen and grab both sides of the screen with both hands. Pull the screen along the rail, and then turn the screen along the rail to push the hotel partition to its proper position. Fix the screen.



Technical Information

Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 80mm / 85mm 100mm
Panel height Up to 4000mm Up to 6000mm Up to 18000mm
Max height 4000mm 6000mm 18000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame Aluminum frame Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire safety Optional Class I or O Optional Class I or O Optional Class I or O
Vertical profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles
Retractable seals Aluminum black with
double rubber seals
Aluminum black with double rubber seals Aluminum black with double rubber seals
Operation of seals Manual, with supplied
operating handle
Manual, with supplied operating handle Manual, with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass doors Single open in panel or
double open in two panel
Single open in panel or double open in two panel Single open in panel or double open in two panel
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx30-48kg/sq M
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)

Office Temporary Divider Aluminum Frame Sliding Folding Movable Wall Partitions 0





Moveable Wall Partitions Features



Individual panels that can be stored away for maximum space usage.


Operable top and bottom seals for effortless operation.


Aluminum frame construction for enhanced acoustics.


The system offers various levels of sound reduction.


Unique track and carrier system ensuring quiet and easy operation.


Numerous panel stacking options for complete flexibility.


Top hung and no floor track.


Extensive range of moveable wall partitions surface finishes can be availabled.
