Ballroom Fire Resistant Acoustic Movable Removable Folding Partition Wall Panel

Ballroom Fire Resistant Acoustic Movable Removable Folding Partition Wall Panel

Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO 9001
Model Number: Model 65 folding partition wall panel

Payment & Shipping Terms:

Minimum Order Quantity: NO MOQ, small quantity welcome
Price: $82-88 per square meter
Packaging Details: Paper carton, outside with wooden box
Delivery Time: 7-15 days
Payment Terms: T/T, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Folding Partition Wall Panel Color: White
Thickness: 65 Mm Max Height: 4 Meters
Application: Ballroom Partition Wall Feature: Fire Resistant Partition Wall
High Light:

Ballroom Removable Folding Partition

,

65mm Thickness Removable Folding Partition

,

Fire Resistant Ballroom Partition Wall

Product Description

Ballroom Fire Resistant Acoustic Movable Removable Folding Partition Wall Panel

Ballroom Fire Resistant Acoustic Movable Removable Folding Partition Wall Panel





Folding Partition Wall Panel Details



1. Different Types:



Type 65 is suitable to use at 2m-4m height space.

Type 85 is suitable to use at 2m-6m height space.

Type 100 is suitable to use at 2m-8m height space.



2. Each panel load-bearing weight: 225kgs/ 450kgs/ 650kgs



3. Sound insulation coefficient:



Type 65 highest sound insulation coefficient can be reach is 32db.

Type 85 the highest sound insulation coefficient can be reach is 40db.

Type 100 the highest sound insulation coefficient can be reach is 53db.



4. Application: Gymnasium, huge meeting rooms, auditorium, conference center, multifunction room, hotels, banquet hall, exhibitions halls, office etc.


Technical Information



Surface Material
W.G
(kg/sq.m)
Soundproof Factor(db)
Partition Frame
Upper & Bottom Stretching Range(mm)
Thk
(mm)
Partition Load-bearing(KG)
MDF Board
(no melamine paper)

28



38









Aluminum Alloy












15-25






80









450
Plywood Board
28
MDF Board
28
Fireproof Board
32

40
Leather/Fabric Hard Cushion
32
Mgo Boar
42
42
Steel Board
42
44
Leather/Fabric Hard Cushion
(cover the edge)

44

44

110
Leather/Fabric Soft Cushion
(cover the edge)

44

44

110
Remarks:
Suggesting Height is less than 5.5m, be suitable for star class multi-function halls, Large conference centers, high class restaurants, banquet halls and so on.

Ballroom Fire Resistant Acoustic Movable Removable Folding Partition Wall Panel 0



Wood Folding Partitions Features



1. Without ground track.


2. Stable and safe.


3. Sound insulation.


4. Energy-saving insulation.



5. High-effcient fire prevetion.

6. Elegant appearance.

7. Retractable and flexible.

8. Easy storage.

9. Wide spread use.
