Ballroom Fire Resistant Acoustic Movable Removable Folding Partition Wall Panel
Product Details:
| Place of Origin: | Guangzhou, China |
| Brand Name: | EBUNGE |
| Certification: | ISO 9001 |
| Model Number: | Model 65 folding partition wall panel |
Payment & Shipping Terms:
| Minimum Order Quantity: | NO MOQ, small quantity welcome |
|---|---|
| Price: | $82-88 per square meter |
| Packaging Details: | Paper carton, outside with wooden box |
| Delivery Time: | 7-15 days |
| Payment Terms: | T/T, MoneyGram |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Product Name: | Folding Partition Wall Panel | Color: | White |
|---|---|---|---|
| Thickness: | 65 Mm | Max Height: | 4 Meters |
| Application: | Ballroom Partition Wall | Feature: | Fire Resistant Partition Wall |
| High Light: | Ballroom Removable Folding Partition,65mm Thickness Removable Folding Partition,Fire Resistant Ballroom Partition Wall |
||
Product Description
Ballroom Fire Resistant Acoustic Movable Removable Folding Partition Wall Panel
Folding Partition Wall Panel Details
1. Different Types:
Type 65 is suitable to use at 2m-4m height space.
Type 85 is suitable to use at 2m-6m height space.
Type 100 is suitable to use at 2m-8m height space.
2. Each panel load-bearing weight: 225kgs/ 450kgs/ 650kgs
3. Sound insulation coefficient:
Type 65 highest sound insulation coefficient can be reach is 32db.
Type 85 the highest sound insulation coefficient can be reach is 40db.
Type 100 the highest sound insulation coefficient can be reach is 53db.
4. Application: Gymnasium, huge meeting rooms, auditorium, conference center, multifunction room, hotels, banquet hall, exhibitions halls, office etc.
|
Surface Material
|
W.G
(kg/sq.m)
|
Soundproof Factor(db)
|
Partition Frame
|
Upper & Bottom Stretching Range(mm)
|
Thk
(mm)
|
Partition Load-bearing(KG)
|
|
MDF Board
(no melamine paper)
|
28
|
38
|
Aluminum Alloy
|
15-25
|
80
|
450
|
|
Plywood Board
|
28
|
|||||
|
MDF Board
|
28
|
|||||
|
Fireproof Board
|
32
|
40
|
||||
|
Leather/Fabric Hard Cushion
|
32
|
|||||
|
Mgo Boar
|
42
|
42
|
||||
|
Steel Board
|
42
|
44
|
||||
|
Leather/Fabric Hard Cushion
(cover the edge)
|
44
|
44
|
110
|
|||
|
Leather/Fabric Soft Cushion
(cover the edge)
|
44
|
44
|
110
|
|||
|
Remarks:
|
Suggesting Height is less than 5.5m, be suitable for star class multi-function halls, Large conference centers, high class restaurants, banquet halls and so on.
|
|||||
Wood Folding Partitions Features
1. Without ground track.
2. Stable and safe.
3. Sound insulation.
4. Energy-saving insulation.
6. Elegant appearance.
7. Retractable and flexible.
