Ballroom Fireproof Board Acoustic Mobile Partition Sliding Walls

Ballroom Fireproof Board Acoustic Mobile Partition Sliding Walls

Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO 9001
Model Number: Model 100 mobile partition sliding wall

Payment & Shipping Terms:

Minimum Order Quantity: NO MOQ, small quantity welcome
Price: $82-88 per square meter
Packaging Details: Paper carton, outside with wooden box
Delivery Time: 7-15 days
Payment Terms: T/T, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Mobile Partition Sliding Wall System: Suspension System
Thickness: 100 Mm Max Height: 6 Meters
Application: Ballroom Partition Finish: Fireproof Board
High Light:

Ballroom Fireproof Acoustic Mobile Partition

,

55dB Acoustic Mobile Partition

,

Melamine Acoustic Mobile Partition

Product Description

Ballroom Fireproof Board Acoustic Mobile Partition Sliding Walls

Ballroom Fireproof Board Acoustic Mobile Partition Sliding Walls





Mobile Partition Sliding Walls Detail



With the unique multi-layer panel system, our mobile partition sliding wall has excellent acoustic performance with a STC up to 22-55 dB.



Double PVC seals are mounted around the sound proof partitions to provide the highest level of acoustic integrity. More importantly, this fit can also achieve the desired acoustic integrity between two nearby rooms.



The acoustic structure includes multi-layer board at the top and bottom of the sound proof partitions and the glass wool inside. The acoustic performance is up to 40 STC, and the fabric wrapped acoustic panel and perforated MDF panel can be used to reduce echo. The vinyl at all edges help to prolong life time and seal the noise.



These mobile partition sliding walls will be provided in an end-folded configuration to meet a variety of parking requirements and the first panel can be provided as a standard access door.



The mobile partition sliding wall has aluminum profiles, and panels are available for a variety of surface treatments including painted, polished veneer or various standard or high pressure laminate. Fire rated finish panel is also available.

Ballroom Fireproof Board Acoustic Mobile Partition Sliding Walls 0



Technical Information

Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Panel thickness 65mm 85mm 100mm
Max height 4000mm 6000mm 18000mm
Panel width 500-1200 mm 500-1200 mm 500-1200 mm
Face material 9mm 9mm 12 mm
Pass doors Single door or Double door
Sound insulation 28-38dB Rw 28-42dB Rw 32-50dB Rw
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)





Mobile Partition Sliding Walls Application



Studios, recording rooms, listening rooms, rehearsal rooms and more professinally interspace timbre projects.



Theaters, indoor gymnasiums, discos, KTV rooms and more performance and entertainment location.



Meeting rooms, offices, halls, hotels and more sound absorption and secrecy projects.



Air-port, railways, bus-stops, manufactories, workshops and more noise reduction projects.
