Mobile Acoustic Hotel Fabric Folding Partition Walls For Function Hall

Mobile Acoustic Hotel Fabric Folding Partition Walls For Function Hall

Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO 9001
Model Number: Model 85 folding partition walls

Payment & Shipping Terms:

Minimum Order Quantity: NO MOQ, small quantity welcome
Price: $82-88 per square meter
Packaging Details: Paper carton, outside with wooden box
Delivery Time: 7-15 days
Payment Terms: T/T, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Folding Partition Walls Surface: Fabric Partition
Track Material: Aluminum Alloy Function: Space Dividers
Feature: Mobile Partition Application: Hotel Partition Walls
High Light:

Hotel Fabric Folding Partition Walls

,

36db Folding Partition Walls

Product Description

Mobile Acoustic Hotel Fabric Folding Partition Walls For Function Hall

Mobile Acoustic Hotel Fabric Folding Partition Walls for Function Hall





Fabric Folding partition walls details



The fabric folding partition series is the highest specification range of fully operable, individual-panel acoustic partitions system. Acoustic insulation of up to 56dB noise reduction is achieved with a combination of operable top and bottom seals, high performance multiple in fill's and a panel assembly design that allows an acoustic break between the frame and outer layer.



The vertical channels of each panel incorporate polymer inserts that facilitate an acoustic seal when the panels are set out as a wall. Fabric folding partition wall panels are produced in three thickness, 65 mm, 85 mm and 100 mm, depending on acoustic rating.




Technical Information

Series Model 65 Model 85 Model 100
Panel suspension Top hung only Top hung only Top hung only
Panel thickness 65 mm 85 mm 100 mm
Max height 4000 mm 6000 mm 8000 mm
Panel width 600-1230 mm 600-1230 mm 600-1230 mm
Based board thickness 9 mm 9 mm 9 mm
Pass doors selection Single Door or Double Door
Sound insulation 20 – 32 db 28 – 36 db 32 – 50 db
Finish Material Plywood / MDF /Laminate / Melamine / Gypsum
Board / Fabric / Insulation / Fireproof /Wall Paper /Vinyl /Painting /etc,(Customized)

Mobile Acoustic Hotel Fabric Folding Partition Walls For Function Hall 0





Fabric Folding Partition Walls Advantages



Engineering transparency, quality assurance



1. Because it is a factory production,information: The transparency of high compartments is high. There are templates and instructions for each material, no shoddy material will appear;



2. All products passed the test;



3. Because it is an assembly, it is easy to see the effect on the spot.



Product environmental protection



1. There is no damage to the ground. Overhead rails only need to install the rails on the floor or on the load beam or grid; there is no track on the floor.



2. It can perform surface fluorocarbon spraying. Unique aluminum alloy profiles: rail and partition wall aluminum alloy 6063-T6 profiles.



3. Heavy-duty, wear-resistant suspension wheel: The life of the suspension wheel is more than 100,000 times.



4. It is not easy to swing and can be accepted 4 Strong stability: The fabric folding partition wall is fully stable after being pulled out of the lock. Can withstand 50-100 kg of impact force; up to 15 meters.



Soundproofing and fire prevention



1. There are four sealing strips on the upper and lower sides of the door, and two sealing strips on the left and right sides. Maximum sound insulation up to 5 Sound and environmental protection: good sound insulation. The coefficient of the compartment can reach 60 decibels; and use environmental protection data to process.



2. Efficient fire protection, use of high-efficiency fire protection data, fire rating A.
