Convention Center Acoustic Wood Surfaced Movable Wall Partition System

Convention Center Acoustic Wood Surfaced Movable Wall Partition System

Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO 9001
Model Number: Model 65 moveable wall partition

Payment & Shipping Terms:

Minimum Order Quantity: NO MOQ, small quantity welcome
Price: $82-88 per square meter
Packaging Details: Paper carton, outside with wooden box
Delivery Time: 7-15 days
Payment Terms: T/T, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Moveable Wall Partition Application: Convention Center Partition
Max Height: 4 Meters Based Board: MDF
Feature: Acoustical Partition Surface: Wood
High Light:

Acoustic Movable Wall Partition

,

65mm Thickness Movable Wall Partition

Product Description

Convention Center Acoustic Wood Surfaced Movable Wall Partition System

Convention Center Acoustical Wood Surfaced Moveable Wall Partition System




Moveable Wall Partition Details



The frame of the model 65 moveable wall partition refers to the material used for the frame when the door panel is spliced. The 6055-T6 high-hardness aluminum alloy material can be used as the raw material for the partitioning aluminum alloy. The conventional oxidation color can be processed according to the customer's other colors.



The total thickness of the model 65 moveable wall partition frame can be 65mm. According to the thickness of the door panel, there are several models such as 65 type, 85 type and 100 type.



The model 65 moveable wall partition system uses 9mm slots on both sides as the fixed position of the board, and the middle is filled with soundproof cotton. Built-in transmission rod, with the principle of jack, easy to lock the operable walls with the transmission setting, the operable wall is as strong and solid as the solid wall. As long as the moveable wall partition track is pre-buried before the ceiling is made, there is no need to lay the track on the ground.





Technical Information


Series Model 65 Model 85 Model 100
Panel suspension Top hung only Top hung only Top hung only
Panel thickness 65 mm 85 mm 100 mm
Max height 4000 mm 6000 mm 8000 mm
Panel width 600-1230 mm 600-1230 mm 600-1230 mm
Based board thickness 9 mm 9 mm 9 mm
Pass doors selection Single Door or Double Door
Sound insulation 20 – 32 db 28 – 36 db 32 – 50 db
Finish Material Plywood / MDF /Laminate / Melamine / Gypsum
Board / Fabric / Insulation / Fireproof /Wall Paper /Vinyl /Painting /etc,(Customized)

Convention Center Acoustic Wood Surfaced Movable Wall Partition System 0





Moveable Wall Partition FAQ



1. Are you a trading company or a factory ?


Our company was established in Guangzhou city,. We are a manufacturer engaged in moveable wall partition for more than 10 years. Welcome to visit our factory in Foshan.



2.How can you guarantee the quality?


We provide three years warrenty.



3.How to finalize orders?


Please send your room drawing and provide requirements like partition surface finished and soundproof requirements, we will design the moveable wall partition for free. After your confirmation, we can start production.



4.How long is the lead time?

.
Normally 10-25 days upon receiving the deposit, base on the quantity 300 SQM



5.Can you do the installation?



Yes, we can send engineer to guide installtion, details please contact us.

6.How is the soundproof quality ?



From 30dB to 52dB, depends of which type and what moveable wall partition surface finished you need. Contact us and we will provide professional suggestions.
