Five Star Hotel Fabric Removable Acoustic Partition Walls Supplier

Five Star Hotel Fabric Removable Acoustic Partition Walls Supplier

Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO 9001
Model Number: Type 65 acoustic partition walls

Payment & Shipping Terms:

Minimum Order Quantity: NO MOQ, small quantity welcome
Price: $82-88 per square meter
Packaging Details: Paper carton, outside with wooden box
Delivery Time: 7-15 days
Payment Terms: T/T, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Acoustic Partition Walls Application: Five Star Hotel Partition
Finishing: Fabric Track Material: Aluminum Alloy
Color: Grey Weight: 25 Kg/m²
High Light:

32dB Acoustic Partition Walls

,

Fabric Finishing Acoustic Partition Walls

,

Hotel Fireproof Acoustic Partition Walls

Product Description

Five Star Hotel Fabric Removable Acoustic Partition Walls Supplier

Five Star Hotel Fabric Removable Acoustic Partition Walls Supplier




Acoustic partition wall detail



Acoustic partition wall consists of 65-130 mm thick individually moving panels, suspended from an aluminum track only, each removable acoustic partition wall panel to have a top and bottom operable pressure seals and concave/convex interlocking profiles with additional PVC seals.



Each removable acoustic partition wall panel is to be suspended on one four-wheel ball-bearing trolley or two multi-directional polymer trolleys.

The vertical edges are protected by means of an overlapping aluminum trim.



Panel Construction: Provide top reinforcement as required to support panel from suspension components and provide reinforcement for hardware attachment. Fabricate removable acoustic partition wall panels with tight hairline joints and concealed fasteners. Fabricate panels so finished in-place partition is rigid level plumb aligned, with tight joints and uniform appearance; and free of bow warp twist deformation, and surface and finish irregularities.



Acoustic partition walls are constructed of a non-deflecting steel tube frame and aluminum profiles, bolted together.



The frame is cladded with a 9 or 12 mm mdf or plywood board.



The removable acoustic partition wall board is not fixed to the frame, allowed to vibrate independently of the frame.



The removable acoustic partition wall panel cavity is filled with high density mineral wool in accordance with the specified sound insulation requirements.

Five Star Hotel Fabric Removable Acoustic Partition Walls Supplier 0





Technical Information




Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 80mm / 85mm 100mm
Panel height Up to 4000mm Up to 6000mm Up to 18000mm
Max height 4000mm 6000mm 18000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame Aluminum frame Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire safety Optional Class I or O Optional Class I or O Optional Class I or O
Vertical profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles
Retractable seals Aluminum black with
double rubber seals
Aluminum black with double rubber seals Aluminum black with double rubber seals
Operation of seals Manual, with supplied
operating handle
Manual, with supplied operating handle Manual, with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass doors Single open in panel or
double open in two panel
Single open in panel or double open in two panel Single open in panel or double open in two panel
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx30-48kg/sq M
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)





Acoustic partition wall features



Bunge removable acoustic partition wall, to achieve all-round, multi-space perspective flexible separation, can be repeated folding, space reuse, energy saving, simple and generous, fully demonstrated demonstrate the art of interior space of the space.



High quality. The use of environmentally friendly materials, formaldehyde emission in line with national standards {1.5mg / L}, The material has strong, durable (abrasion resistance), fire protection, anti-deformation, anti-flammability, anti-aging, fastness, etc.anti-aging;



High noise. Fully meet the five-star hotel noise standards, the highest sound insulation up to 55db (more than 30% stronger than ordinary indoor wall insulation);



Wide range of applications. Removable acoustic partition wall used in the star hotel Banquet Hall, Conference Room, Exhibition Hall, Office, Multi-Function Hall and other large space need to be divided into places;



Can be customized on demand. Customized according to the different needs of customers, such as cut off the model, surface decoration and collection methods such as design, to meet the different site decoration style.
