United State Acoustic Sliding Door Operable Foldable Partition Wall

United State Acoustic Sliding Door Operable Foldable Partition Wall

Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO 9001
Model Number: Type 100 foldable partition wall

Payment & Shipping Terms:

Minimum Order Quantity: NO MOQ, small quantity welcome
Price: $82-88 per square meter
Packaging Details: Paper carton, outside with wooden box
Delivery Time: 7-15 days
Payment Terms: T/T, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Foldable Partition Wall Application: Office Partition Wall
Finishing: Melamine Based Board: MDF
Feature: Acoustic Partition Weight: 30 Kg/m²
High Light:

MDF Foldable Partition Wall

,

Operable Foldable Partition Wall

,

30kg/m2 Foldable Partition Wall

Product Description

United State Acoustic Sliding Door Operable Foldable Partition Wall

United State Acoustic Sliding Door Operable Foldable Partition Wall




How to operate the foldable partition walls?



1 .Be certain to retract the top and bottom before moving panel or damage may occur.



2. Not for outdoor using, put the the foldable partition wall panel stay away from and water or moisture area.



3. Take care of the foldable partition wall panel finishing during installation or operating and the fabric and leather fabric is not easy to clean spotted or damaged.



4. The foldable partitions only operated by the trained personnel.



5. Operate slowly and never force the partition panel.



6. Slowly turning every time at the “T” and “L” corner track.



7. If get stuck or not smooth and “T or “L: corner track, turn back to push again.

United State Acoustic Sliding Door Operable Foldable Partition Wall 0





Technical Information





Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 80mm / 85mm 100mm
Panel height Up to 4000mm Up to 6000mm Up to 18000mm
Max height 4000mm 6000mm 18000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame Aluminum frame Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire safety Optional Class I or O Optional Class I or O Optional Class I or O
Vertical profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles
Retractable seals Aluminum black with
double rubber seals
Aluminum black with double rubber seals Aluminum black with double rubber seals
Operation of seals Manual, with supplied
operating handle
Manual, with supplied operating handle Manual, with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass doors Single open in panel or
double open in two panel
Single open in panel or double open in two panel Single open in panel or double open in two panel
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx30-48kg/sq M
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)





How to maintain and repair the foldable partition walls?



Conduct all operations slowly. Safe operation requires moving panels into place one at a time. Avoid stopping while moving the panels through intersections. The carriers may stop in an intersection and appear stuck. If this happens, push panel back in the direction from which it came and try again.



For the best acoustical seal and proper alignment, it is important to maintain constant pressure against the edge of the panel while setting seals.



If you notice that a foldable partition wall is not hanging plumb, stop and go back and reset the panel. If you fail to do this, panels will not make full contact and provide a poor acoustic seal.



The foldable partition walls consists of seal panel (SP), basic panel(BP), an optional pass door,(PD), additional basic panels(BP), and telescopic panel(TP). Stand in the center of the panel face. Using both hands, grasp it by the edges as high as possible and gently pull it toward you. (exp.a) Carefully maneuver the panel out of the storage area. Move the foldable partition wall panel down the track to the required position. Once in place, push it firmly against the adjacent wall or panel to insure a tight joint. You may place your foot against the bottom of the panel to hold it in place while you extend the acoustical seals.

United State Acoustic Sliding Door Operable Foldable Partition Wall 1
