Philippines Demountable Foldable Acoustic Operable Movable Partition Walls

Philippines Demountable Foldable Acoustic Operable Movable Partition Walls

Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO 9001
Model Number: Type 100 foldable room dividers

Payment & Shipping Terms:

Minimum Order Quantity: NO MOQ, small quantity welcome
Price: $82-88 per square meter
Packaging Details: Paper carton, outside with wooden box
Delivery Time: 7-15 days
Payment Terms: T/T, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Foldable Room Dividers Application: Office Partition Wall
System: With Ceiling Wheel Based Board: MDF
Feature: Sound Proofing Surface: Laminate
High Light:

Demountable Operable Movable Partition Walls

,

32db Operable Movable Partition Walls

Product Description

Philippines Demountable Foldable Acoustic Operable Movable Partition Walls

Philippines Demountable Foldable Acoustic Operable Movable Partition Walls




How to collect the movable partition walls?



1. If the movable partition wall has a pass door, open the door and retract the seals by reversing the previous setup instructions. Close the door and make certain that it is latched.



2. Retract the telescopic panel by inserting the operating key over the shaft in the face of the panel and turn counter-clockwise to retract the closure. Retract top and bottom seals on this panel by placing the key over the shaft in the trail edge and rotate counter-clockwise.



3. Panels with Retractable Seals: Insert operating key onto the shaft of each panel and fully rotate key counter-clockwise, retracting the top and bottom seal. Before moving the panel, make certain that the seals have retracted. Please do not move panels if the seals are not retracted - permanent damage could result. Separate panels and move to storage area. Repeat until all panels are stacked. Note: Floor pins may be present when two partitions form a "T". They must also be retracted before moving panel(s).

Philippines Demountable Foldable Acoustic Operable Movable Partition Walls 0





Technical Information


Series Model 65 Model 85 Model 100
Panel suspension Top hung only Top hung only Top hung only
Panel thickness 65 mm 85 mm 100 mm
Max height 4000 mm 6000 mm 8000 mm
Panel width 600-1230 mm 600-1230 mm 600-1230 mm
Based board thickness 9 mm 9 mm 9 mm
Pass doors selection Single Door or Double Door
Sound insulation 20 – 32 db 28 – 36 db 32 – 50 db
Finish Material Plywood / MDF /Laminate / Melamine / Gypsum
Board / Fabric / Insulation / Fireproof /Wall Paper /Vinyl /Painting /etc,(Customized)





How to maintain and repari the movable partition walls?



Conduct all operations slowly. Safe operation requires moving panels into place one at a time. Avoid stopping while moving the panels through intersections. The carriers may stop in an intersection and appear stuck. If this happens, push panel back in the direction from which it came and try again.



For the best acoustical seal and proper alignment, it is important to maintain constant pressure against the edge of the panel while setting seals.



If you notice that a partition is not hanging plumb, stop and go back and reset the panel. If you fail to do this, panels will not make full contact and provide a poor acoustic seal.



The movable wall consists of seal panel (SP), basic panel(BP), an optional pass door,(PD), additional basic panels(BP), and telescopic panel(TP). Stand in the center of the panel face. Using both hands, grasp it by the edges as high as possible and gently pull it toward you. (exp.a) Carefully maneuver the panel out of the storage area. Move the panel down the track to the required position. Once in place, push it firmly against the adjacent wall or panel to insure a tight joint. You may place your foot against the bottom of the panel to hold it in place while you extend the acoustical seals.
