Lebanon Ceiling Track Mobile Training Room Acoustic Partition Walls

Lebanon Ceiling Track Mobile Training Room Acoustic Partition Walls

Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO9001
Model Number: Type 85 acoustic partition walls

Payment & Shipping Terms:

Minimum Order Quantity: 1 square meter
Price: USD86-140/m²
Packaging Details: Paper carton, outside with wooden box.
Delivery Time: Negotiable
Payment Terms: T/T
Supply Ability: 50000 m² per month
Get Best Price Contact Now

Detail Information

Product Name: Acoustic Partition Walls Application: Training Room Partition
Feature: Mobile Thickness: 85 Mm
Height: Max 6 Meters Width: Max 1220 Mm
High Light:

85mm Thickness Acoustic Partition Walls

,

1220mm Width Acoustic Partition Walls

Product Description

Lebanon Ceiling Track Mobile Training Room Acoustic Partition Walls

Lebanon Ceiling Track Mobile Training Room Acoustic Partition Walls


How is the sound insulation effect for acoustic partition walls?

1. Horizontal sound insulation


In order to achieve the sound insulation effect, the structure of two layers of sound insulation rubber is adopted. Using the jack principle, the double-layer rubber strips are pressed tightly on the ceiling track and the floor to provide high-stability movable partitions.


2. Corner sound insulation


The use of special shaped rubber corner components solves the technical problem of sealing the corners; at the same time, it also achieves superior stability and sound insulation.


3. Vertical sound insulation


All sound-proof acoustic partition walls adopt highly flexible vertical close-fitting sides, and the principle of tightly fitting concave-convex grooves to ensure closure and sound insulation.


4. Skeleton


In view of the hanging structure of the wall panels, it can be shaken freely, and the metal hoops between the wall panels are tightly combined, effectively blocking the transmission of sound. The acoustic partition wall panel can be replaced according to the needs of the interior design without destroying the entire wall panel.


5. Sound insulation material


The acoustic partition walls frame is filled with additional sound insulation materials to meet different sound insulation requirements.


6. Operate the crank


Manually operate the crank to control the expansion and contraction of the sound insulation strip. The flexible elasticity of the diamond-shaped connection bayonet in the crank makes the crank not easy to slide.


7. Panel


The wallboard frame is composed of aluminum alloy and steel pipe. This strong and non-deformable frame is closely combined with the metal hoops of the acoustic partition wall panel to provide great stability and high sound insulation.
Lebanon Ceiling Track Mobile Training Room Acoustic Partition Walls 0




Advantages


The appearance of training room acoustic partition walls has brought great convenience to people's lives. Whether it is conference halls, exhibition halls, restaurants, high-clean factories and other places, the unique mobility of acoustic partition wall allows it to show its skills in these fields. Specifically, the use of acoustic partition wall has the following advantages:


1. It can be moved and reused many times. The material of the compartment system hardly brings waste to the environment. It is a green building material with a long service life. In the long run, the installation of latal high compartment system materials is better than other forms of installation. training room acoustic partition walls materials are more cost-effective.


2. During usage, the positions of doors, windows, physical modules, and glass partitions can be changed at any time, and they can be recombined and reused. After the materials are disassembled, the damage is minimal, and the cost of frequent office relocation can be greatly reduced.


3. The internal structure allows easy cable laying. It does not need to be buried in the wall, the maintenance and replacement of the cable are more convenient, the strong and the weak electricity are separated, and the cable trough can play a shielding role for the signal line.
4. Fast installation, each person can install more than 15 square meters per day.


5. Fire-resistant and fire-resistant. The compartment system is entirely composed of metal structures. Materials such as glass and color steel plates are also fire-resistant. The fire resistance of the materials of the compartment system can reach 30, 60 or 90 minutes.


6. No pollution or odor emission, it can be used immediately after installation.


7. The training room acoustic partition walls frame has a sealing strip, the door leaf is a trapezoidal side, and the door frame is a trapezoidal opening, which improves the sound insulation effect and sealing performance.


8. The glass door lock can be installed in the middle, which is extremely convenient to use.


9. Venetian blinds can be installed inside, not easy to get dirty, no cleaning.


10. Good sound insulation effect, the acoustic partition wall has very good sound insulation effect.


11. A variety of material choices, you can choose double glass plus venetian blinds, or color steel plate, gypsum board, melamine board, fireproof board, cloth fleece, etc.


12. A variety of colors are available for you to choose, each material has a variety of colors, and components of different colors can be used together. Even the finishing materials of any color and texture can be specified or provided by you.


13. The construction noise is small. Does not affect the work and life of people around.


14. The effect is fashionable, elegant, concise and exquisite.

Lebanon Ceiling Track Mobile Training Room Acoustic Partition Walls 1



Technical Details



Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Panel thickness 65mm 85mm 100mm
Max height 4000mm 6000mm 18000mm
Panel width 500-1200 mm 500-1200 mm 500-1200 mm
Face material 9mm 9mm 12 mm
Pass doors Single door or Double door
Sound insulation 28-38dB Rw 28-42dB Rw 32-50dB Rw
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)
