Floor To Ceiling Meeting Room Division Wooden Acoustic Partition Walls
Product Details:
| Place of Origin: | Guangzhou, China |
| Brand Name: | EBUNGE |
| Certification: | ISO9001 |
| Model Number: | Type 65 acoustic partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 square meter |
|---|---|
| Price: | USD86-140/m² |
| Packaging Details: | Paper carton, outside with wooden box. |
| Delivery Time: | Negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 50000 m² per month |
|
Detail Information |
|||
| Product Name: | Acoustic Partition Walls | Package: | Paper Carton Or Wooden Box |
|---|---|---|---|
| MOQ: | No MOQ, Small Quantity Welcome | Color: | Color Chart Optional |
| Filling Material: | Soundproof Cotton | Frame Material: | Aluminum Alloy |
| High Light: | Meeting Room Acoustic Partition Walls,1200mm Acoustic Partition Walls,32db Acoustic Operable Partitions |
||
Product Description
Floor to Ceiling Meeting Room Division Wooden Acoustic Partition Walls
Product Description
The frame of the 65-type acoustic partition walls refers to the material used for the frame when the door panel is spliced. The 6055-T6 high-hardness aluminum alloy material can be used as the raw material for the partitioning aluminum alloy. The conventional oxidation color can be processed according to the customer's other colors.
The total thickness of the 65-type partition frame can be 65mm. According to the thickness of the door panel, there are several models such as 65 type, 85 type and 100 type.
The 6-type acoustic partition walls uses 9mm slots on both sides as the fixed position of the board, and the middle is filled with soundproof cotton. Built-in transmission rod, with the principle of jack, easy to lock the acoustic partition wall with the transmission setting, the fixed partition wall is as strong and solid as the solid wall. As long as the track is pre-buried before the ceiling is made, there is no need to lay the track on the ground.
The sliding track is grooved, and with the correct screws it becomes possible to attach angle irons, for example for a false ceiling, without damaging the sliding track. The various surface finishes and wide range of colors ensure that the creativity employed will complement the architecture of the office perfectly.
The cover sheets are inter-changeable, allowing a new color scheme to be introduced at any moment. High-precision ball bearings guarantee a smooth slide and minimum sound, at a maximum weight of 150kg of the leaf. The various positioning possibilities of the panels (parallel/at 90° to the sliding track, or other) ensure that a solution is found to every requirement. The sliding track may be straight, curved or have a polygonal shape.
Advantages
1. Reinforced aluminium frame construction for demanding condition.
2. Wide range of movable partitions board surface finishes and colors.
3. Single or double passdoor enabling access to neighbouring rooms.
4. The movable partition board stacking can be one or both ends.
5. Top hung and floor with rubber seals achieving excellent soundproof effect.
6. Various levels of soundproof reduction.
Technical Details
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65mm | 85mm | 100mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9mm | 9mm | 12 mm |
| Pass doors | Single door or Double door | ||
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Finish Material |
Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) |
||
FAQ
Q1. Can I have a sample order for movable partition board?
A: We can provide a free movable partition board sample to every clients, but also welcome to our showroom to discuss more.
Q2. What about the lead time?
A:Sample needs 5 - 7 days, mass production time needs 2 - 4 weeks for order quantity more than 300 square meters.
The shipping time is around 10-35 days based on the different countries.
Q3. Do you have any MOQ limit for movable partition board?
A: No MOQ, small quantity welcomed.
Q4. How do you ship the movable partition board and how long does it take to arrive?
A: We usually ship by sea. It usually takes 2-5 weeks to arrive based on the different countries. By air is also available.
Q5. How to proceed an order for movable partition board?
A: Firstly, please send us the drawing or the size about project site.
Secondly, we quote according to your requirements or our suggestions.
Thirdly, customer confirms the drawing and places deposit to us.
Fourthly, we arrange the production.
Q6: Do you offer guarantee for the movable partition board?
A: Yes, we offer 3 - 5 years warranty.
