US Acoustic Operable Room Divider Movable Wooden Partition Wall For Auditoriums

US Acoustic Operable Room Divider Movable Wooden Partition Wall For Auditoriums

Product Details:

Place of Origin: Guangzhou,China
Brand Name: EBUNGE
Model Number: Series 65 mm folding partition walls

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Price: 60-119 USD per square meter
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face.
Delivery Time: Shipped in 10 days after payment, based on the quantity.
Payment Terms: D/A, D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability: 5000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Acoustic Room Divider Material: Aluminium And Mdf Board
Height: Less Then 4 M Width: 500-1200 Mm
Thickness: 65mm Aluminum Frame Function: Space Dividing
Finish: Melamine, Fabric, Leather, MDF Bare Finish Warranty: Sliding Partition Walls Warranty 3-5 Years
High Light:

1200mm Operable Room Divider

,

Insulation Operable Room Divider

,

Auditoriums Movable Wooden Partition Wall

Product Description

US acoustic operable room divider movable wooden partition wall for auditoriums

Description:

Equipped with our signature Acousti-Seal technology, EBUNGE’s operable partitions represent one of the most flexible solutions to making the most of your interior space. With our operable partitions, room sizes can be changed in a matter of moments to control sound and capitalize on the most efficient use of floor space.

US Acoustic Operable Room Divider Movable Wooden Partition Wall For Auditoriums 0

Technical parameters:

Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 80mm / 85mm 100mm
Panel height Up to 4000mm Up to 6000mm Up to 18000mm
Max height 4000mm 6000mm 18000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame Aluminum frame Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire safety Optional Class I or O Optional Class I or O Optional Class I or O
Vertical profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles
Retractable seals Aluminum black with
double rubber seals
Aluminum black with double rubber seals Aluminum black with double rubber seals
Operation of seals Manual, with supplied
operating handle
Manual, with supplied operating handle Manual, with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass doors Single open in panel or
double open in two panel
Single open in panel or double open in two panel Single open in panel or double open in two panel
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx30-48kg/sq M
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)

US Acoustic Operable Room Divider Movable Wooden Partition Wall For Auditoriums 1

Single Panel
For the largest openings, storage in remote pockets, and complex partition layouts, the Acousti-Seal single panel system is the perfect fit. EBUNGE’s single panel systems provide the ultimate in versatility and flexibility, allowing such capabilities as multiple room setups and changes in the location of pass doors and work surfaces.



Paired Panel

For straight-line openings that do not require multiple locations or offset storage, an Acoustic-Seal paired panel system is ideal. Quick and easy setup is possible since panels are hinged together in groups of two and move in a straight line within the opening.



Designer Line
Let your imagination run wild. Acoustic-Seal Designer Line offers a unique platform for artistic partition solutions. Whether aiming to achieve a unique design for the operable partition or to match existing walls within your space, EBUNGE has the capability to customize your operable partition with a variety of finishes, murals, window, and glass options.

US Acoustic Operable Room Divider Movable Wooden Partition Wall For Auditoriums 2

Enhance your EBUNGE partitions by adding standard or customized options and accessories. They provide solutions that can improve the safety, functionality, and security of your facility, as well as add to its aesthetic appeal. Choose from an array of custom applications, including window cutouts, moldings, spinner panel walls, barn door sliders, telescoping sliders, sloped floors or risers, and locking expandable closure.
