Fireproof Board Office Room Sliding Partition Wall Sound Proof
Product Details:
| Place of Origin: | Guangzhou, China |
| Brand Name: | EBUNGE |
| Certification: | ISO 9001 |
| Model Number: | 65 mm sliding partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | No MOQ, small quantity welcome |
|---|---|
| Price: | $98-$115 per square meter. |
| Packaging Details: | Paper carton, outside with wooden box. |
| Delivery Time: | 7-15 days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| General Use: | Soundproof Partition Walls Are Used For Interior Decoration | Material: | Aluminium,MFC |
|---|---|---|---|
| Size: | Partition Wall Customized | Application: | Commercial Building And Residential House |
| Product Name: | Acoustic Partition Walls,soundproof Partition Walls | Advantage: | Professional Design Team&factory Manufacture&fashionable Outlook |
| Function: | Office Partition Wall,soundproof | Service: | OEM/ODM,ODM |
| High Light: | Fireproof Sliding Partition Wall,acoustic Office Room Partition Wall |
||
Product Description
Fireproof Board Office Room Sliding Partition Wall Sound Proof
1.Specification:
The acoustic office room brings great convenience to people's work. The mobile partition is a movable wall that divides a large space into small spaces at any time according to needs or connects small spaces into large spaces and has general wall functions. The area can serve as a multi-purpose room and a multi-purpose room.
2.Technical Information:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 65mm | 80mm / 85mm | 100mm |
| Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
| Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
| Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
| Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
| Pass doors | Single open in panel or double open in two panel |
Single open in a panel or double open in two panel | Single open in a panel or double open in two panel |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wallpaper, Vinyl, Painting, etc. (Customized) | ||
3.Installing Description:
(1)Install the acoustic panels: the installation of acoustic panels should be carried out in a sequence from the left to the right, from upside to downside, the panels are cut to fit on-site, traditional woodworking tools are suitable for cutting the panels, if panels are cut using a fine tooth table saw the panels should be cut face up to avoid scratching and at a much slower speed to avoid any tear-out or chipping.
(2)Fix on keel:
Wooden keel fixing using nails, staples, or screws into prefixed timber battens on the walls via the tongue and groove joint. It also can fix by light steel keel.
