Hotel Movable Partition Wall Construction System Sliding Wall Well Done

China Hotel Movable Partition Wall Construction System Sliding Wall Well Done supplier
Hotel Movable Partition Wall Construction System Sliding Wall Well Done supplier Hotel Movable Partition Wall Construction System Sliding Wall Well Done supplier Hotel Movable Partition Wall Construction System Sliding Wall Well Done supplier

Large Image :  Hotel Movable Partition Wall Construction System Sliding Wall Well Done

Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO 9001
Model Number: 65 mm folding partition walls

Payment & Shipping Terms:

Minimum Order Quantity: No MOQ, small quantity welcome
Price: $82-128 per square meter.
Packaging Details: Paper carton, outside with wooden box.
Delivery Time: 7-15 days
Payment Terms: T/T, Western Union
Supply Ability: 50000 square meters per month
Contact Now
Detailed Product Description
General Use: Soundproof Partition Walls Are Used For Interior Decoration Type: Folding Partition
Material: MDF,Aluminium Color: Customized
Thickness: 65~125mm Product Name: Acoustic Partition Walls,soundproof Partition Walls
Feature: Soundproof Surface Treatment: Melamine,etc
Finishing Option: Melamine,wall Paper
High Light:

Construction System Sliding PartitionWall

,

125mm Hotel Movable Partition Wall

Hotel movable partition wall construction system sliding wall well done



1. Details



Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 80mm / 85mm 100mm
Panel height Up to 4000mm Up to 6000mm Up to 18000mm
Max height 4000mm 6000mm 18000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame Aluminum frame Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire safety Optional Class I or O Optional Class I or O Optional Class I or O
Vertical profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles
Retractable seals Aluminum black with
double rubber seals
Aluminum black with double rubber seals Aluminum black with double rubber seals
Operation of seals Manual, with supplied
operating handle
Manual, with supplied operating handle Manual, with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass doors Single open in panel or
double open in two panel
Single open in panel or double open in two panel Single open in panel or double open in two panel
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx30-48kg/sq M
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)



Hotel Movable Partition Wall Construction System Sliding Wall Well Done 0



2.Description:



The flexibility of movable partitions can be divided or combined according to the different needs of different occasions. The use of an active partition can create a good decorative effect in the integration of the overall style of the room, and it also acts as a partition of the partition itself.



The color of the partition is rich and colorful, and the colors are appropriately matched according to the owner's preference or the style of the room, and the permeability is enough to ensure privacy. At the same time, it is also possible to use some partitions with sound insulation as required.



Hotel Movable Partition Wall Construction System Sliding Wall Well Done 1



3.Sliding soundproof partition aluminum accessories:



Track: The tracks are made from extruded 6063 - T5 anodized aluminum.



The track housing shall utilize grooves and interlocking steel pins for positive alignment of adjacent track sections, and shall be reinforced overhead by drop rod brackets. The aluminum track housing shall include an integral nut slot to accept a hardened square nut for attaching each drop rod bracket to the top of the track.



Hotel Movable Partition Wall Construction System Sliding Wall Well Done 2
