Restaurant Movable Partition Wall System Install Well Done
Product Details:
Place of Origin: | Guangzhou, China |
Brand Name: | EBUNGE |
Certification: | ISO 9001 |
Model Number: | 65 mm soundproof partition wall |
Payment & Shipping Terms:
Minimum Order Quantity: | No MOQ, small quantity welcome |
---|---|
Price: | $82-98 per square meter. |
Packaging Details: | Paper carton, outside with wooden box. |
Delivery Time: | 7-15 days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 50000 square meters per month |
Detail Information |
|||
General Use: | Soundproof Partition Walls Are Used For Interior Decoration | Type: | Folding Partition |
---|---|---|---|
Material: | MDF,Aluminium | Size: | Customized,Partition Wall Customized |
Thickness: | 65mm | Style: | Modern |
Product Name: | Acoustic Partition Walls,soundproof Partition Walls | Advantage: | Soundproof |
Surface Treatment: | Melamine | Frame Material: | Aluminium |
High Light: | 65mm Movable Partition Wall System,Soundproof Movable Partition Wall |
Product Description
Restaurant movable partition wall system install well done
1.Description:
The flexibility of movable partitions can be divided or combined according to the different needs of different occasions. The use of an active partition can create a good decorative effect in the integration of the overall style of the room, and it also acts as a partition of the partition itself.
The color of the partition is rich and colorful, and the colors are appropriately matched according to the owner's preference or the style of the room, and the permeability is enough to ensure privacy. At the same time, it is also possible to use some partitions with sound insulation as required.
Series | BG65 | BG85 | BG100 |
Panel suspension | Top hung only | Top hung only | Top hung only |
Track system | Single or twin point | Single or twin point | Single or twin point |
Panel thickness | 65mm | 80mm / 85mm | 100mm |
Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
Max height | 4000mm | 6000mm | 18000mm |
Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
Face material | 9mm | 9mm / 12mm | 12mm |
Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) |
2. Details
Due to this great flexibility in changing rooms’ sizes, any venues ranging from the small meeting rooms to a large exhibition hall can be altered to suit varying numbers of users. Operable walls are popular in exhibition and convention halls, hotels, conference rooms, auditorium and training centers.
Operable walls are also able to meet many sophisticated requirements such as segmented architectural curve walls and stepped floor. And with a maximum height limit of 15 meters, Operable walls are able to fulfill many complex designs.
3.Installation:
(1)Size of the wall: all panels should be installed in accordance with the manufacturer's recommendations.
(2)Cutting: all necessary hardware and accessories for a complete job installation are to be furnished by the contractor.
(3)Install the acoustic panels: the installation of acoustic panels should be carried out in a sequence from the left to the right, from upside to downside, the panels are cut to fit on-site, traditional woodworking tools are suitable for cutting the panels, if panels are cut using a fine tooth table saw the panels should be cut face up to avoid scratching and at a much slower speed to avoid any tear-out or chipping.
(4)Fix on keel: Wooden keel fixing using nails, staples, or screws into prefixed timber battens on the walls via the tongue and groove joint. It also can be fixing by a light steel keel.
