Sliding Glass Partition Single Types Of Glass Partition Wall Office Partition
Product Details:
| Place of Origin: | Guangzhou, China |
| Brand Name: | EBUNGE |
| Certification: | ISO 9001 |
| Model Number: | 36 mm sliding glass partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | No MOQ, small quantity welcome |
|---|---|
| Price: | $90-$115 per square meter. |
| Packaging Details: | Paper carton, outside with wooden box. |
| Delivery Time: | 7-15 days |
| Payment Terms: | T/T, Western Union, |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Material: | Glass And Frame | General Use: | Commercial Furniture |
|---|---|---|---|
| Type: | Commercial Furniture | Color: | Accept Customized |
| Thickness: | 32mm | Style: | Sliding |
| Advantage: | Sliding And Folding | Service: | OEM/ODM, ODM |
| Glass: | Double And Single Tempered Glass, Laminated Glass Or Insulated Glass, Single Glass/Double Glass, Single/laminated/hollow/triple/tinted/tempered/clear | ||
| High Light: | Single Sliding Glass Partition Wall,32mm Office Glass Partition Wall |
||
Product Description
Sliding glass partition single types of glass partition wall design office partition
1.Bunge Glass Partition Systems-Technical Information
| Series | BG65 Glazing Glass Partition | BG85 Aluminum Frame Glass Partition | BG85 Soundproof Glass Partition |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 36mm | 85mm | 85mm |
| Panel height | Up to 3000mm | Up to 6000mm | Up to 6000mm |
| Max height | 3000mm | 6000mm | 6000mm |
| Panel width | 800-1100mm | 800-1100mm | 800-1100mm |
| Frame construction | Top and bottom aluminum | Aluminum frame | Aluminum frame |
| Glass thickness | 10mm single glass | 10mm or 12mm single glass | double 10mm glass |
| Fire safety | Optional Class O | Optional Class O | Optional Class O |
| Vertical profiles | n/a | n/a | Aluminum anodized with sealing profiles |
| Retractable seals | n/a | n/a | Aluminum black with double rubber seals |
| Operation of seals | n/a | n/a | |
| Pass doors | Fixed full height door | Fixed full height door | Fixed full height door |
| Locking | Optional lock to panel | Optional lock to panel | Optional lock to panel |
| Sound insulation | n/a | n/a | n/a |
| Weight | Approx 30 kg/sq M | Approx 32 kg/sq M | Approx 50 kg/sq M |
2.Common Applications:
(1). Theaters, indoor gymnasiums, discos, KTV rooms, and more performance and entertainment locations.
(2). Studios, recording rooms, listening rooms, rehearsal rooms, and more professionally interspace timbre projects.
(3). Air-port, railways, bus-stops, manufactories, workshops, and more noise reduction projects.
(4). Meeting rooms, offices, halls, hotels, and more sound absorption and secrecy projects.
3. FAQ
(1). Do you have an installer in our country?
We can private the free install video and documents to you, then according to the videos and documents, anyone can do that.
(2). How can we fix the glass partition wall?
We according to the floor lock fix the glass partition wall, we will show you fix video.
(3). How can we solve the after-services?
We have the warranty 3years and hardware 5 years when happening problem that we can from video call explain how to solve and free arrange hardware to you.
(4). How to transport to our country?
We make the EXW or CIF if you have China agent that we can make EXW, if you do not have the agent that we will arrange an agent to handle shipment to your port, then you will Customs clearance and pick up the shipment from port warehouse.
4.Package
