Payment & Shipping Terms:
|Product Name:||Folding Partition Walls||Material:||MDF With Melamine|
|Color:||Customized||Service:||ODM & OEM|
|Finish:||Melamine;fabric;leather||Package:||Standard Wooden Case|
|Frame Material:||Aluminum Alloy Profile||Max Height:||8000 MM|
|Thickness:||100 MM||Application:||Hotel; Office; Art Gallery|
|Transport:||Sea Transportation; Air Transportation In Emergency Condition||Condition:||New|
|Style:||Simple & Modern||Sample:||Free|
Movable Door Inflatable Wall Partition Room Divider Folding Partition Wall For Meeting Room
|Panel suspension||Top hung only||Top hung only||Top hung only|
|Track system||Single or twin point||Single or twin point||Single or twin point|
|Panel thickness||65mm||80mm / 85mm||100mm|
|Panel height||Up to 4000mm||Up to 6000mm||Up to 18000mm|
|Frame construction||Aluminum frame||Aluminum frame||Aluminum frame|
|Face material||9mm||9mm / 12mm||12mm|
|Fire safety||Optional Class I or O||Optional Class I or O||Optional Class I or O|
|Vertical profiles||Aluminum anodised with sealing profiles||Aluminum anodised with sealing profiles||Aluminum anodised with sealing profiles|
|Retractable seals||Aluminum black with
double rubber seals
|Aluminum black with double rubber seals||Aluminum black with double rubber seals|
|Operation of seals||Manual, with supplied
|Manual, with supplied operating handle||Manual, with supplied operating handle|
|Locking||Optional lock to pass doors||Optional lock to pass doors||Optional lock to pass doors|
|Pass doors||Single open in panel or
double open in two panel
|Single open in panel or double open in two panel||Single open in panel or double open in two panel|
|Sound insulation||20-32dB Rw||28-36dB Rw||32-50dB Rw|
|Weight||Approx 22-35kg/sq M||Approx 25-40kg/sq M||Approx30-48kg/sq M|
|Finish Material||Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)|
Bunge Movable Partition Wall Advantages:
1. Bunge latest roller POM materials to meet its best wearing resistant, the high carbon chromium bearing steel has reach to a strength 10.9 grade.
2. Bunge's vertical crank handle shaft made by 304 stainless steel LCP panel crank handle shaft cup and operable handle.
3. Bunge double corrosion-resistant aluminum track systems are easy to install and easier to maintain. Extruding enable each section to have a uniform for superior end-to-end alignment. Each capacity-certified track is of extrude architectural grade clear anodized 6063-T6 aluminum.
4. The safety and stability of movable partition are effected by what kind of keel materials used inside in structure. Bunge use both the 6063-T6 aluminum keels and wood keels, keeps every two keels at a distance max no more than 600mm.
5. To seal the corner, Bunge gets its own design about specially developed conically shaped corner pieces that fit closely together. They ensure excellent soundproofing and stability.
6. Bunge's vinyl seals are made of Nitrile Butadiene Rubber (NBR), durable and perfect for sound installation, and long time wearing.
1. Individual panels that can be stored away for maximum space usage.
2. Operable top and bottom seals for effortless operation.
3. Aluminum frame construction for enhanced acoustics.
4. The system offers various levels of sound reduction.
5. Unique track and carrier system ensures quiet and easy operation.
6. Numerous panel stacking options for complete flexibility.
7. Top hanging and no floor track.
8. Extensive range of surface finishes can be available.
1.Q: Are you a manufacturer or trading company?
A: We are a famanufacturer, and this is our address: No.39-2, Nanwei Road, Hailong street, Longxi Avenue, Liwan District, Guangdong Province, China.
2. Q: What is the price of the movable wall?
A: Our mobile wall system is customized, the cost is calculated by area, the thickness of different walls and the price of different finishes are different. Therefore, we need you to provide us detailed dimensions such as height, width and finish requirements. If possible, we also need your layout drawings.
3. Q: Is the movable partition acoustic (soundproof)?
A: Yes, our movable wall system is soundproof. We have different acoustic material fillings and various sound absorbing panels to achieve different acoustic ratings. For the 65 series we can reach 45db, for the 80 type we can reach 48db, the 85 type can reach 50db, for the 100 type we can reach 50db.
4.Q: How to install an active partition? Is it difficult to complete?
A: It is not difficult to install our active partitions. Our active partition is a hanging rail type moving wall that does not require any ground track. Therefore the hanging rail structure will be very important. We have very detailed drawings and videos showing how to install, so your employees just need to follow them step by step.
5.Q: Do you provide sample?
A: Yes, and the sample is free, you just pay the express delivery fee is ok.
6.Q: What is your payment terms?
A : 30% - 50% of total amount by T/T as deposit when confirmed the order and balance paid by T/T before loading container, or irrevocable L/C at sight.
7. Q : What is your warranty ? What do we do in case of problems?
A : 3 years quality warranty is provided, including frame unfading nor peel-off, hardware and accessories working properly under correct operation.In case of our quality problem, we will provide replacement by international courier. Immediate delivery of replacement parts with available in stock, and if not stocking, the time should be depending on material ordering time which is normally 10- 15 days.
