Product Details:

Place of Origin: Guangdong, China
Brand Name: EBUNGE
Model Number: 65 MM

Payment & Shipping Terms:

Minimum Order Quantity: 1 square meter
Price: Negotiable
Packaging Details: Carton paper packing ,MDF Batten cover all over the corner
Delivery Time: 7-28 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Movable Partition Wall Material: MDF With Melamine
Color: Customized Service: ODM & OEM
Finish: Melamine;fabric;leather Package: Standard Wooden Case
Frame Material: Aluminum Alloy Profile Max Height: 4000 MM
Thickness: 65 MM Base Board: 9 MM
Drawing: Free
High Light:

movable walls on wheels

,

movable partitions systems

Product Description

Movable Walls Auditorium Acoustic Partition Walls Soundproof Movable Partition Walls [Ebunge partition]

Movable partition wall

Series BG65 BG85 BG100
Panel suspension Top hung only
Panel thickness 65mm 85mm 100mm
Max height 4000mm 6000mm 8000mm
Panel width 600-1230mm
Face material 9mm 9mm 12mm
Sound insulation 20-32db RW 30-38db RW 35-45db RW
Weight 20-30 kg/sq M 22-35kg/sq M 28-40kg/sq M
Track system Single or two point
Frame construction Aluminum frame
Finish materials Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)



The effective division of space sometimes requires utmost flexibility. Whether the requirement is to divide a teaching area, temporarily partition a conference suite, or simply create extra rooms out of one large space, the answer is movable partition walls. Bunge has movable walls, operable walls, sliding folding partitions. Alongside Bunge operable walls, the products also include, hinged partitions and concertina olding partitions along with a range of glass movable walls and industrial doors. Bunge provides unrivalled experience in the design and manufacture of space utilisation products.



Soundproof Movable Partition Walls / Auditorium Acoustic Partition Walls 0



The installation of partition:

A beam(truss) should be built on site for track installation. The minimum distance leaving for track installation from false ceiling to top ceiling is 180 mm.

We will provide the installation manual and video guiding the installation job. We can also dispatch the installation engineer supervising the installation as request.



Transport and delivery:

Sea transport is a common mode of transportation. In an emergency, can be air freight.

Carton paper packaging, MDF batten cover all around corner.

The movable wall panel and track, fittings will be packed separately.



Soundproof Movable Partition Walls / Auditorium Acoustic Partition Walls 1


FAQ

1.Q: Are you a manufacturer or trading company?

A: We are a famanufacturer, and this is our address: No.39-2, Nanwei Road, Hailong street, Longxi Avenue, Liwan District, Guangdong Province, China.



2. Q: What is the price of the movable wall?

A: Our mobile wall system is customized, the cost is calculated by area, the thickness of different walls and the price of different finishes are different. Therefore, we need you to provide us detailed dimensions such as height, width and finish requirements. If possible, we also need your layout drawings.



3. Q: Is the movable partition acoustic (soundproof)?

A: Yes, our movable wall system is soundproof. We have different acoustic material fillings and various sound absorbing panels to achieve different acoustic ratings. For the 65 series we can reach 45db, for the 80 type we can reach 48db, the 85 type can reach 50db, for the 100 type we can reach 50db.



4.Q: How to install an active partition? Is it difficult to complete?

A: It is not difficult to install our active partitions. Our active partition is a hanging rail type moving wall that does not require any ground track. Therefore the hanging rail structure will be very important. We have very detailed drawings and videos showing how to install, so your employees just need to follow them step by step.



5.Q: Do you provide sample?

A: Yes, and the sample is free, you just pay the express delivery fee is ok.



6.Q: What is your payment terms?

A : 30% - 50% of total amount by T/T as deposit when confirmed the order and balance paid by T/T before loading container, or irrevocable L/C at sight.



7. Q : What is your warranty ? What do we do in case of problems?

A : 3 years quality warranty is provided, including frame unfading nor peel-off, hardware and accessories working properly under correct operation.In case of our quality problem, we will provide replacement by international courier. Immediate delivery of replacement parts with available in stock, and if not stocking, the time should be depending on material ordering time which is normally 10- 15 days.
