Auto CAD Design Acoustic Room Dividers / Foldable Wall Partition
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | EBUNGE |
| Model Number: | 65 MM |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 square meter |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton paper packing ,MDF Batten cover all over the corner |
| Delivery Time: | 7-28 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000 square meters per month |
|
Detail Information |
|||
| Product Name: | Acoustic Room Dividers | Material: | MDF With Melamine |
|---|---|---|---|
| Color: | Customized | Function: | Soundproof Room Dividers |
| Service: | ODM & OEM | MOQ: | NO MOQ |
| Finish: | Melamine; Fabric; Leather | Package: | Standard Wood Case |
| Frame Material: | Aluminum Alloy Profile | Height: | 4000 MM |
| Thickness: | 65 MM | Board Thickness: | 9 MM |
| Application: | Office;hotel;classroom;museum;exhibition | ||
| High Light: | acoustic operable partitions,movable acoustic partition walls |
||
Product Description
Ebunge Auto CAD Design acoustic room dividers foldable wall Ebunge partition
Product Description:
1. Poduction: 10000 squre meters per month;
2. All products are customized;
3. Three series for different choice:
65mm-up to 4ms H; 85mm-up to 6ms H;100mm-up to 13ms H;
4. Panels width: 500mm to 1200mm, also can 2ms width for special request;
5. Panels height: up to 15meters height.
6. Panels thickness: 65mm-(2 9/16)", 85mm-(3 3/8)", 100mm-(3 15/16)",
7. Sound proof: from 20db to 53db.
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | ||
| Panel thickness | 65mm | 85mm | 100mm |
| Max height | 4000mm | 6000mm | 8000mm |
| Panel width | 600-1230mm | ||
| Face material | 9mm | 9mm | 12mm |
| Sound insulation | 20-32db RW | 30-38db RW | 35-45db RW |
| Weight | 20-30 kg/sq M | 22-35kg/sq M | 28-40kg/sq M |
| Track system | Single or two point | ||
| Frame construction | Aluminum frame | ||
| Finish materials | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Sound proof partitions features
1. No rail suspension: The floor has no track, just install the track on the ceiling;
About BUNGE Factory
We are a professional comprehensive sound proof partitions Manufacturer in Guangzhou, China, we have our own factory and showroom and we believe that we can meet your demand,very welcome to visit us! May be we are not the only one supplier for you,but we are sure that we are a good choice for you!
In addition, we have a team of professional engineerers who can supervise the sound proof partitions installation all over the world. They have been to India, Malaysia, Uganda, Lebanon, Philippines, Indonesia and so on. So if our client have any question in installation, we can help them install the removable partition walls smoothly and quickly.
Packaging & Shipping
Partition wall when we finished production, we will use carton packing and mdf board to pack movable panels.
And we will also make one or more packing boxes for clients.It can reduce damagement during transportation.
We usually transport movable panels by sea, such as CIF price.
Some aluminium profile,sliding track,glass clips and other accessories we can transport by courier, like DHL or Fedx.
FAQ
1. Are you a manufacturer or trading company?
We are a manufacturer, and this is our address: No.39-2, Nanwei Road, Hailong street, Longxi Avenue, Liwan District, Guangdong Province, China.
2. What is the price of the movable wall?
Our mobile wall system is customized, the cost is calculated by area, the thickness of different walls and the price of different finishes are different. Therefore, we need you to provide us detailed dimensions such as height, width and finish requirements. If possible, we also need your layout drawings.
3. Is the movable partition acoustic (soundproof)?
Yes, our movable wall system is soundproof. We have different acoustic material fillings and various sound absorbing panels to achieve different acoustic ratings. For the 65 series we can reach 45db, for the 80 type we can reach 48db, the 85 type can reach 50db, for the 100 type we can reach 50db.
4. Q: How to install an active partition? Is it difficult to complete?
It is not difficult to install our active partitions. Our active partition is a hanging rail type moving wall that does not require any ground track. Therefore the hanging rail structure will be very important. We have very detailed drawings and videos showing how to install, so your employees just need to follow them step by step.
5. Q: Do you provide sample?
Yes, and the sample is free, you just pay the express delivery fee is ok.
6. Q: What is your payment terms?
30% - 50% of total amount by T/T as deposit when confirmed the order and balance paid by T/T before loading container, or irrevocable L/C at sight.
7. Q : What is your warranty ? What do we do in case of problems?
3 years quality warranty is provided, including frame unfading nor peel-off, hardware and accessories working properly under correct operation.In case of our quality problem, we will provide replacement by international courier. Immediate delivery of replacement parts with available in stock, and if not stocking, the time should be depending on material ordering time which is normally 10 - 15 days.
Very velcome to visit our Web and contact us!
Send us a question below to get a movable wall catolog and special discounts!
