Restaurant Movable Partition Room Partition Divider Custom Made

China Restaurant Movable Partition Room Partition Divider Custom Made supplier
Restaurant Movable Partition Room Partition Divider Custom Made supplier Restaurant Movable Partition Room Partition Divider Custom Made supplier Restaurant Movable Partition Room Partition Divider Custom Made supplier Restaurant Movable Partition Room Partition Divider Custom Made supplier Restaurant Movable Partition Room Partition Divider Custom Made supplier Restaurant Movable Partition Room Partition Divider Custom Made supplier

Large Image :  Restaurant Movable Partition Room Partition Divider Custom Made

Product Details:

Place of Origin: Guangdong, China
Brand Name: EBUNGE
Model Number: 65 MM

Payment & Shipping Terms:

Minimum Order Quantity: 1 square meter
Price: Negotiable
Packaging Details: Carton paper packing ,MDF Batten cover all over the corner
Delivery Time: 7-28 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000 square meters per month
Contact Now
Detailed Product Description
Product Name: Acoustic Room Dividers Material: MDF With Melamine
Color: Customized Function: Soundproof Room Dividers
Service: ODM & OEM MOQ: NO MOQ
Finish: Melamine; Fabric; Leather Package: Standard Wood Case
Frame Material: Aluminum Alloy Profile Height: 6000 MM
Width: 500 - 1230 Mm Condition: New
Sample: Optional

Restaurant movable partition room partition divider Chinese restaurant room partition wholesale custom-made

In restaurant, we sometimes need to divide a large space into several small rooms or combine some small space into a large one. If you are involved in this kind of need, movable partition can be your choice. Bunge Building Decoration Company is a professional company specializing in partition manufacture for more than 10 years. IWe have adopted the advanced partition company of USA, Germany and Denmark. The goal of our company is to provide the best space solution to our customers and satisfy them with our professional services.

Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 80mm / 85mm 100mm
Panel height Up to 4000mm Up to 6000mm Up to 18000mm
Max height 4000mm 6000mm 18000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame Aluminum frame Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire safety Optional Class I or O Optional Class I or O Optional Class I or O
Vertical profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles
Retractable seals Aluminum black with
double rubber seals
Aluminum black with double rubber seals Aluminum black with double rubber seals
Operation of seals Manual, with supplied
operating handle
Manual, with supplied operating handle Manual, with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass doors Single open in panel or
double open in two panel
Single open in panel or double open in two panel Single open in panel or double open in two panel
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx30-48kg/sq M

Restaurant Movable Partition Room Partition Divider Custom Made



How to install the partition?

1.Track installation:Suspension fixed way is at the top of the partition board install the hanging wheel, and connected to the track suspension. The track and hanging wheel should be chosen according to the partition size and load weight.
2.Partition panel installation: according to the design drawing, draw on each partition panel to mark the line wheel, fix the wheel with screws on the partition board top; Then the panel be put into track, let each panel in the perpendicular to the ground; Test and push-pull flexible rotation, and finally to fixed connection.
3.Debugging: movable panel need to discretion, sealing and so on debugging after installed. Then cleaning up the panel, complete the installation work

Restaurant Movable Partition Room Partition Divider Custom Made

Accessories details:

Track: The tracks are made from extruded 6063 - T5 anodized aluminium. The track housing shall utilize grooves and interlocking steel pins for positive alignment of adjacent track sections, and shall be reinforced overhead by drop rod brackets. Aluminum track housing shall include an integral nut slot to accept a hardened square nut for attaching each drop rod bracket to the top of the track.

Panels:The Panels will be made from 12mm MDF boards and shall be 100mm thick and 1230mm maximum width, made to the appropriate acoustic rating and structural backing and mounted in full perimeter extruded aluminium frames with interlocking corner construction .The panel faces shall be finished with selected material.

Panel Surface Finish:The panel surface will be as per the clients requirement finished either in Sliwal factory - China or by others. The normal finish such as:laminate,veneer,melamine,fabric etc.

Seals: vinyl seal of butane rubber will be used as top and bottom and as well as closure seals for the operable wall system.Retractable seal drop will be 23mm.

Restaurant Movable Partition Room Partition Divider Custom Made

How do the movable partition wall work?
1. The continuously hinged panels are pulled from their parked position to 'close' (or extend) the wall and pushed back to the parked position to 'open' (or fold)the wall. Final flat alignment of wall panels is assisted pneumatically by a gas piston located in the top track. A lever or recess handle is fitted to the lead panel and this combined with a vertical rebated profile provides the system with its pass door. The door is available with or without a lock cylinder.
2. Our easy lock-up set.
Retractable pressure seals on top and bottom are extended and retracted by a single 180°turn removable operating handle.
3. Retractable Pressure Seals.
Once the panel is positioned, they are sealed in place with retractable pressure seals.
4. Telescopic sleeve panel.
Final closure of the wall is achieved by extending a telescopic sleeve on the last panel. The sweep strip simultaneously extends the top and bottom. The rubber sealing strip on the side edge of telescopic panelcan seal the wall tightly to reach acoustic integrity.

Restaurant Movable Partition Room Partition Divider Custom Made

FAQ

1. Are you a manufacturer or trading company?

We are a manufacturer, and this is our address: No.39-2, Nanwei Road, Hailong street, Longxi Avenue, Liwan District, Guangdong Province, China.



2. What is the price of the movable wall?

Our mobile wall system is customized, the cost is calculated by area, the thickness of different walls and the price of different finishes are different. Therefore, we need you to provide us detailed dimensions such as height, width and finish requirements. If possible, we also need your layout drawings.



3. Is the movable partition acoustic (soundproof)?

Yes, our movable wall system is soundproof. We have different acoustic material fillings and various sound absorbing panels to achieve different acoustic ratings. For the 65 series we can reach 45db, for the 80 type we can reach 48db, the 85 type can reach 50db, for the 100 type we can reach 50db.



4. Q: How to install an active partition? Is it difficult to complete?

It is not difficult to install our active partitions. Our active partition is a hanging rail type moving wall that does not require any ground track. Therefore the hanging rail structure will be very important. We have very detailed drawings and videos showing how to install, so your employees just need to follow them step by step.



5. Q: Do you provide sample?

Yes, and the sample is free, you just pay the express delivery fee is ok.



6. Q: What is your payment terms?

30% - 50% of total amount by T/T as deposit when confirmed the order and balance paid by T/T before loading container, or irrevocable L/C at sight.



7. Q : What is your warranty ? What do we do in case of problems?

3 years quality warranty is provided, including frame unfading nor peel-off, hardware and accessories working properly under correct operation.In case of our quality problem, we will provide replacement by international courier. Immediate delivery of replacement parts with available in stock, and if not stocking, the time should be depending on material ordering time which is normally 10 - 15 days.
