Acoustic Sliding Folding Movable Partition Walls For Meeting Room
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | EBUNGE |
| Model Number: | 100 MM |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 square meter |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton paper packing ,MDF Batten cover all over the corner |
| Delivery Time: | 7-28 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000 square meters per month |
|
Detail Information |
|||
| Product Name: | Movable Partition Walls | Material: | MDF With Melamine |
|---|---|---|---|
| Color: | Customized | Function: | Soundproof Partition Wall Panels |
| Service: | ODM OEM | MOQ: | NO MOQ |
| Finish: | Melamine | Package: | Standard Wooden Case |
| Frame Material: | Aluminum Alloy Profile | Height: | 8000 Mm |
| Thickness: | 100 MM | ||
| High Light: | movable walls on wheels,movable partitions systems |
||
Product Description
Acoustic sliding folding partition conference room movable partition wall for meeting room
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 65mm | 80mm / 85mm | 100mm |
| Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
| Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
| Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
| Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
| Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
Application:
Our products can divide a large space into several small rooms which are widely used in hotel banquet hall, meeting room, exhibition hall, conference room, international convention center, KTV, upscale restaurants, office building, schools, hospitals and others.
Operation:
When moving a wall panel, there is a 20-25mm gap between the top of the panel and the underside of the head track and there is a similar gap between the bottom of the panel and the floor.
Once a panel is positioned, acoustic integrity is maintained along the top and bottom of the panel by extending pressure seals. The pressure seals are extended and retracted by a single 180° turn of a removable operating handle.
Final closure of the wall is achwared by extending a telescopic sleeve on the last panel. This action simultaneously extends the top and bottom seals.
Key Features & Benefits:
Partition thickness: 100mm
All frame adopt aluminum alloy # 6063-T6
Height can reach 16m
Sound insulation co-efficient:55db
Retracted range of retracted panel:150mm
Apply to large exhibition center, gym, etc.
Surface:
Different surface use in different areas.Our main surface is mdf melamine, it can be more easy to clean.
Also fabric and leather surface is very popular in conference room or banquet hall.
And like dancing room or classroom,client prefer mirror surface.
Also we can design surface pu leather with printing photos.
If client prefer to paint color on panels, we suggest Mdf bare finish.If prefer to glue wallpaper, plywood surface is a good choice.
Packaging & Shipping
We have clients from all over the world,they are satisfied with our soundproof movable partition walls.
When they came to our factory, they all surprised at our environment and our technology.
There are a big movable wall show room in our factory, with different finish samples. Like glass partition, melamine partition, leather partition, fabric partition etc.
Sliding partition wall when we finished production, we will use carton packing and mdf board to pack movable panels.
And we will also make one or more packing boxes for clients.It can reduce damagement during transportation.
We usually transport movable panels by sea, such as CIF price.
Some aluminium profile,sliding track,glass clips and other accessories we can transport by courier, like DHL or Fedex.
Our service:
1. Profession--We have professional sales staff. Any questions will be replied within 24 hours.
2. Price--Because we are factory,so we can provide nice quality and lower price products.
3. Service--Easy and convenient to transport,we promise timely delivery date, and good after-sale service.
4. Team--We have our own engineering department, according to your request for your tailor-made for your product.
5. Installing--Our engineer can come to teach installing,and we will also supply installing drawings and video
| Free Sample in 10 Days Inquiry now and you will have your sample in 10 day if you pay the express. | 3-year Warranty The acoustic room divider made of 6063-T5 alumina, anti-aging, no fading and abrasion in 10 years | OEM Service Your logo can be printed on the packaging carton |
FAQ
1. What the Movable Partition Wall use for?
They are the creative way to add flexibility and functionality to your space.extensively applied to star hotels, meeting rooms, ballrooms, clubs, banquet hall, convention centers, multi-function halls, training rooms and other facilities.
2. Have your partition wall products come in standard sizes?
No, actually all of our movable partition wall sizes are supported customized. The panels move on the ceiling track with no floor track.
3. How long does it take to install a partition system?
We will provide a detailed schedule on receipt of the order and keep everything updated regularly on progress. The time depends very much on the site and anything which we try to meet wherever possible.
4. Can you give us an initial indication of the cost of a particular system?
Yes.we can. We would need more information and possibly a site visit and survey before confirming and exact price.
5. Do I need to have an architect or building contractor?
Usually we only offer the site supervision service.if you are already using another contractor for other work then we can work with them to ensure a smooth process.
6. Do I need to provide technical information or drawings?
Yes, we need. If you already have technical information or drawing then we can use them to build and install the selected
products.
7. Are your products guaranteed?
Yes,all of our products carry a full 3 Year guarantee,covering all parts and defects. We can also provide an extended warranty if require and the products are expected to last a lifetime.
