Auto CAD Design BG-85 Series Folding Partition Walls Conference Room
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | EBUNGE |
| Model Number: | 85 MM |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 square meter |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton paper packing ,MDF Batten cover all over the corner |
| Delivery Time: | 7-28 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000 square meters per month |
|
Detail Information |
|||
| Product Name: | Folding Partition Walls | Material: | MDF With Melamine |
|---|---|---|---|
| Color: | Customized | Function: | Soundproof Partition Wall Panels |
| Service: | ODM OEM | MOQ: | NO MOQ |
| Finish: | Melamine | Package: | Wooden Case |
| Frame Material: | Aluminum Alloy Profile | Height: | 6000 Mm |
| Country: | China | ||
| High Light: | acoustic folding partition,folding room partitions |
||
Product Description
China AutoCAD Design supplier Ebunge partition BG-85 series folding partition wall conference room folding partition
| Product name | Folding Partition Walls |
| Color | Customized |
| Material of Frame | Aluminum Frame |
| Material of Soundproofing | Wooden Board, aluminum frame |
| Application | Room Divider |
| Style | Modern Banquet Hall Folding Partitions |
| Size | Customizied |
| Feature | Assemble |
| Service | OEM ODM |
| Finish | Melamine, fabric or customized |
| Product Keywords | partition wall,acoustic wall partition,kitchen acoustic wall |
The effective division of space some times requires utmost flexibility. Whether the requirement is to divide a teaching area, temporarily partition a conference suite or simply create aextra rooms out of one large space, the answer is folding partition.
Applications:
The panel is a range of folding wall systems that incorporates two panels (each up to 900mm wide) that are hinged together to give a flush appearance when closed.
Folding walls are quick to operate and are available in a range of acoustic rating from 30db-49db. Sound attenuation is achieved by modern manufacturing methods and the unique panel construction that consists of an aluminum frame, particle board cladding and multiple acoustic infills.
Advantages:
Individual panels that can be stored away for maximum space usage.
Operable top and bottom seals for effortless operation.
Aliminum frame construction for enhanced acoustics.
The system offers various levels of sound reduction.
Unique track and carrier system ensuring quiet and easy operation.
Numerous panel stacking options for complete flexibility.
Top hanging and no floor track.
Extensive range of surface finishes can be available.
Pass door self-lock system:
Using strong force spring press device to fix the pass door (door-in-door) instead of the fixing method with ground spike that can destory the land.
Surface
Different surface use in different areas.Our main surface is mdf melamine, it can be more easy to clean.
Also fabric and leather surface is very popular in conference room or banquet hall.
And like dancing room or classroom,client prefer mirror surface.
Also we can design surface pu leather with printing photos.
If client prefer to paint color on panels, we suggest Mdf bare finish.If prefer to glue wallpaper, plywood surface is a good choice.
Construction:
Tracks: Made of good quality anodized aluminium 6063-T5 materials,hanging the retractable partitions panels with wheels.
Wheels/Rollers: It is the carrier for the retractable partitions,let the panels move more flexibly.Pulley bearing is more than 1600 KGS.
Connectors: Made of anodized aluminium 6063-T5 aluminum tracks,"L", "T", "+"types are available.
Rubber/vinyl seal: Made of Nitrile Butadiene Rubber(NBR+PVC),durable and perfect for sound insulation,wear-resistant.
Rock Wool: Density of 60kg/m3,help us reduce the noise and heat.
Handle: Operate the retractable being up and down.
Retractable mechanism: Control the movement of the top and bottom seal to form a excellent sound insulation performance.
Magnetic Strip: Ferrite plastic magnetic material will be used in between aluminum profiles to enhance acoustic performance of the retractable partitions.
MDF board: 9 mm thickness,density of 760kg/m3,absorbent thickness expansion rate is less than 15%.Formaldehyde emission is 34mg/100g.
FAQ
1. What the Movable Partition Wall use for?
They are the creative way to add flexibility and functionality to your space.extensively applied to star hotels, meeting rooms, ballrooms, clubs, banquet hall, convention centers, multi-function halls, training rooms and other facilities.
2. Have your partition wall products come in standard sizes?
No, actually all of our movable partition wall sizes are supported customized. The panels move on the ceiling track with no floor track.
3. How long does it take to install a partition system?
We will provide a detailed schedule on receipt of the order and keep everything updated regularly on progress. The time depends very much on the site and anything which we try to meet wherever possible.
4. Can you give us an initial indication of the cost of a particular system?
Yes.we can. We would need more information and possibly a site visit and survey before confirming and exact price.
5. Do I need to have an architect or building contractor?
Usually we only offer the site supervision service.if you are already using another contractor for other work then we can work with them to ensure a smooth process.
6. Do I need to provide technical information or drawings?
Yes, we need. If you already have technical information or drawing then we can use them to build and install the selected
products.
7. Are your products guaranteed?
Yes,all of our products carry a full 3 Year guarantee,covering all parts and defects. We can also provide an extended warranty if require and the products are expected to last a lifetime.
