Customized Color Folding Partition Wall Doors Aluminium 6000mm Height
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | EBUNGE |
| Model Number: | 85 MM |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 square meter |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton paper packing ,MDF Batten cover all over the corner |
| Delivery Time: | 7-28 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000 square meters per month |
|
Detail Information |
|||
| Product Name: | Folding Partition Wall | Material: | MDF With Melamine |
|---|---|---|---|
| Color: | Customized | Function: | Soundproof Partition Wall Panels |
| Service: | ODM OEM | MOQ: | NO MOQ |
| Finish: | Melamine | Package: | Standard Wooden Case |
| Frame Material: | Aluminum Alloy Profile | Height: | 6000 Mm |
| Thickness: | 85 Mm(3 1/4 Inch) | ||
| High Light: | acoustic folding partition,folding room partitions |
||
Product Description
Folding partition wall doors folding partition wall aluminium
| Model | BG65 | BG85 | BG100 |
| Suspension System | Hanging System, with ceiling rails | ||
| Basic Thickness | 65mm | 85mm | 100mm |
| Max Height | Max 3800mm | Max 6000mm | Max 8000mm |
| Width | 800 -1230mm | ||
| Floor/ceiling Sealing strength |
Telescopic aluminum tube with rubber strip | ||
| Side Walls Sealing Strength |
Double seal tape | ||
| Base Board Thickness | 9 mm | 9 mm | 12 mm |
| Vertical Profiles | Aluminum anodised with sealing profiles | ||
| Retractable Seals | Aluminum black with double rubber seals | ||
| Operation | Manual System, with supplied operating handle | ||
| Pass Doors | Single or Double Pass Through Door Available | ||
| Weight | Approx 22-35 kg/m² | Approx 25-40 kg/m² | Approx30-48 kg/m² |
Applications:
The panel is a range of folding wall systems that incorporates two panels(each up to 900 mm wide) that are hinged together tp give a flush appearance when closed.
Folding walls are quick to operate and are available in a range of acoustic ratings from 30db-49db. Sound attenuation is achieved by modern manufacturing methods and the unique panel construction that consists of an aluminum frame, particle board cladding and multiple acoustic infills.
Key Features & Benefits:
Individual panels that can be stored away for maximum space usage.
Operable top and bottom seals for effortless operation.
Aluminum frame construction for enhanced acoustics.
The system offers various levels of sound reduction.
Unique track and carrier system ensuring quiet and easy operation.
Numerous panel stacking options for complete flexibility.
Top hanging and no floor track.
Extensive range of surface finishes can be available.
Operation:
When moving a wall panel, there is a 20-25 mm gap between the top of the panel and the underside of the head track and there is a similar gap between the bottom of the panel and the floor.
Once a panel is positioned, acoustic integrity is maintained along the top and bottom of the panel by extending presure seals. The presure seals are extended and retracted by a single 180° turn of a removable operating handle.
Final closure of the wall is achwared by extending a telescopic sleeve on the last panel. This action simultaneously extends the top and bottom seals.
Tansport: Sea transport is a common mode of transportation. In an emergency, can be air freight.
Goods packing: Carton paper packaging, MDF batten cover all around corner.
The movable wall panel and track, fittings will be packed separately.
Panel Stacking Options:
FAQ
1. What the Movable Partition Wall use for?
They are the creative way to add flexibility and functionality to your space.extensively applied to star hotels, meeting rooms, ballrooms, clubs, banquet hall, convention centers, multi-function halls, training rooms and other facilities.
2. Have your partition wall products come in standard sizes?
No, actually all of our movable partition wall sizes are supported customized. The panels move on the ceiling track with no floor track.
3. How long does it take to install a partition system?
We will provide a detailed schedule on receipt of the order and keep everything updated regularly on progress. The time depends very much on the site and anything which we try to meet wherever possible.
4. Can you give us an initial indication of the cost of a particular system?
Yes.we can. We would need more information and possibly a site visit and survey before confirming and exact price.
5. Do I need to have an architect or building contractor?
Usually we only offer the site supervision service.if you are already using another contractor for other work then we can work with them to ensure a smooth process.
6. Do I need to provide technical information or drawings?
Yes, we need. If you already have technical information or drawing then we can use them to build and install the selected
products.
7. Are your products guaranteed?
Yes,all of our products carry a full 3 Year guarantee,covering all parts and defects. We can also provide an extended warranty if require and the products are expected to last a lifetime.
