Payment & Shipping Terms:
|Product Name:||Folding Partition Walls||Material:||MDF With Melamine|
|Color:||Customized||Function:||Soundproof Partition Wall Panels|
|Service:||ODM OEM||MOQ:||NO MOQ|
|Finish:||Fabric; Leather; Melamine||Package:||Standard Wooden Case|
|Frame Material:||Aluminum Alloy Profile||Height:||4000 Mm|
acoustic folding partition,
folding room partitions
Modern folding partition walls prices supplier China folding wall for room separation and space division
Application of partition wall:
Our products are widely used in the hotel banquet hall, meeting room, exhibition hall, conference room, International convention center, KTV, upscale restaurants, office building, school, hospitals and others.
The panel is a range of folding wall systems that incorporates two panels (each up to 900 mm wide) that are hinged together to give a flush appearance when closed.
Folding walls are quick to operate and are available in a range of acoustic rating from 30db-49db. Sound attenuation is achieved by modern manufacturing methods and the unique panel construction that consists of an aluminum frame, particleboard cladding and multiplr acoustic infills.
|Panel suspension||Top hung only||Top hung only||Top hung only|
|Track system||Single or twin point||Single or twin point||Single or twin point|
|Panel thickness||65mm||80mm / 85mm||100mm|
|Panel height||Up to 4000mm||Up to 6000mm||Up to 18000mm|
|Frame construction||Aluminum frame||Aluminum frame||Aluminum frame|
|Face material||9mm||9mm / 12mm||12mm|
|Fire safety||Optional Class I or O||Optional Class I or O||Optional Class I or O|
|Vertical profiles||Aluminum anodised with sealing profiles||Aluminum anodised with sealing profiles||Aluminum anodised with sealing profiles|
|Retractable seals||Aluminum black with
double rubber seals
|Aluminum black with double rubber seals||Aluminum black with double rubber seals|
|Operation of seals||Manual, with supplied
|Manual, with supplied operating handle||Manual, with supplied operating handle|
|Locking||Optional lock to pass doors||Optional lock to pass doors||Optional lock to pass doors|
|Pass doors||Single open in panel or
double open in two panel
|Single open in panel or double open in two panel||Single open in panel or double open in two panel|
|Sound insulation||20-32dB Rw||28-36dB Rw||32-50dB Rw|
|Weight||Approx 22-35kg/sq M||Approx 25-40kg/sq M||Approx30-48kg/sq M|
1. The sliding partition wall is a hanging system, which have the ceiling rails, but have no floor reails. So it will not damage the floor or carpet at the project site.
2. All of the sliding partition walls can be customized, such as the size, the colors and the surfaces.
3. The sliding partition walls can help you divide a big space into 2 or more smaller rooms. When you do not use them, they can be parked to the parking zone conveniently and quickly.
4. The operation is very easy, 1 person can finish the whole operation.
5. More than 60 kinds of colors to choose.
6. Different surfaces also available. Such as the MDF, Plywood, Melamine, Veneer, Fabric and Leather surface.
7. Single or Double Pass Door also available, which can help you come in and out easily.
1. What the Movable Partition Wall use for?
They are the creative way to add flexibility and functionality to your space.extensively applied to star hotels, meeting rooms, ballrooms, clubs, banquet hall, convention centers, multi-function halls, training rooms and other facilities.
2. Have your partition wall products come in standard sizes?
No, actually all of our movable partition wall sizes are supported customized. The panels move on the ceiling track with no floor track.
3. How long does it take to install a partition system?
We will provide a detailed schedule on receipt of the order and keep everything updated regularly on progress. The time depends very much on the site and anything which we try to meet wherever possible.
4. Can you give us an initial indication of the cost of a particular system?
Yes.we can. We would need more information and possibly a site visit and survey before confirming and exact price.
5. Do I need to have an architect or building contractor?
Usually we only offer the site supervision service.if you are already using another contractor for other work then we can work with them to ensure a smooth process.
6. Do I need to provide technical information or drawings?
Yes, we need. If you already have technical information or drawing then we can use them to build and install the selected
7. Are your products guaranteed?
Yes,all of our products carry a full 3 Year guarantee,covering all parts and defects. We can also provide an extended warranty if require and the products are expected to last a lifetime.
