Office Removable Wall Partitions Movable Office Room Divider Walls With Doors
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | EBUNGE |
| Model Number: | 65 MM |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 square meter |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton paper packing ,MDF Batten cover all over the corner |
| Delivery Time: | 7-28 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000 square meters per month |
|
Detail Information |
|||
| Product Name: | Movable Partition Walls | Material: | MDF With Melamine |
|---|---|---|---|
| Color: | Customized | Function: | Soundproof Partition Wall Panels |
| Service: | ODM OEM | MOQ: | NO MOQ |
| Finish: | Melanimine | Package: | Standard Wood Case |
| Frame Material: | Aluminum Alloy Profile | Height: | 4000 MM |
| Condition: | New | ||
| High Light: | movable walls on wheels,movable partitions systems |
||
Product Description
Office removable wall partitions movable office room divider walls with doors
About Bunge:
Bunge is a partition manufacturer, devoting in this industry of over 10 years. We have our own factory and professional engineers. Our products have occupied more than 80 countries and enjoyed a good reputation.
About Partition:
If you want to divide your large room into several small ones, partition will be the best choice. Our partitions apply the advance technology, which can meet you need. And this kind of product is customized, all your requirement can be negotiable.
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 65mm | 80mm / 85mm | 100mm |
| Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
| Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
| Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
| Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
| Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
Application of partition:
1. Studios, recording rooms, listening rooms, rehearsal rooms and more professionally interspace timbre projects.
2. Theaters, indoor gymnasiums, discos, KTV rooms and more performance and entertainment location.
3. Meeting rooms, offices, halls, hotels ,class room and more sound absorption and secrecy projects
4. Air-port, railways, bus-stops, manufacture, workshops and more noise reduction projects.
Packaging & Delivery
BUNGE Movable Partition Wall standard packing used carton paper for Full container loading, if only LC Loading, will use wooden box for the panels packing.
Packing details is Carton package, MDF batten on four section sides ,foam board on both front face.
For special surface, like glass partition wall we can get wooden boxes packing for you.
Sea transport is a common mode of transportation.In an emergency, can be air freight.
FAQ
1: What you should you do on site?
A beam (truss)should built on site for track installation.The minimum distance leaving for track installation from false ceiling to top ceiling is 180mm.
2: How to install?
We will provide the installation manual and video guiding the installation job.We can also dispatch the installation engineer supervising the installation as request.
3: What is lead time ?
The lead time is 7 days to 10days.
4: How to ransport?t
Sea transport is a common mode of transportation.In an emergency,can be air freight .
5: How do the goods packing?
Carton paper package ,MDF batten cover all around cotner.
6: What is procurement procedure?
Firstly, seng us the shop drawing (if the shop drawings is not available ,you can tell us the height from false ceiling to finfshed floor and width from wall to wall)Secondly, we offer you the movable wall layout drawings for your confirmation.Thirdly, we quote the movable wall in acordance with confirmed
7: What is the finishing surface?
The bottom panel is MDF or plywood, which is unfinished face.
You can do decoration on site, such as wallpaper, paint, etc,
We can also provide the product with finished face, such as melamine, faux wood, woven fabric and leather.
8. How to select the suitable movable wall for your site?
We have 4 types of movable wall, 65 type, 85 type, 100 type and 125 ultra-high type.
You can choose the right movable wall upon the height and soundproof requirement as following,
65 type: Max height: 4000 mm (160inch), soundproof 20-28 db
85 type: Max height: 6000 mm (240 inch), soundproof 25-36 db
100 type: Max height: 7000 mm (275 inch), soundproof 30-50 db
125 type: Max height: 15000 mm (590 inch), soundproof 35-55 db
Welcome to visit our Website and contact us!
Send us a question below to get a movable wall catolog and special discounts!
