1) Folding room partition movable wall interlocking male / female trapezoidal vertical aluminium profiles, for soundproof connection between elements.
2) Folding room partition movable wall to ensure additional friction connection, shall be integrated with magnetic strip.
3) Folding room partition is easy element adjustment after installation.
4) Folding room partition movable wall track system shall be Extruded aluminium, maintenance free with heavy -duty ball bearing steel rollers.
5) Folding room partition movable wall surface panel shall be of 9 mm or 12 mm MDF with acoustic treatment to the required level.
|
Series
|
BG65
|
BG80 / BG85
|
BG100 & BG125
|
|
Panel suspension
|
Top hung only
|
Top hung only
|
Top hung only
|
|
Track system
|
Single or twin point
|
Single or twin point
|
Single or twin point
|
|
Panel thickness
|
65mm
|
80mm / 85mm
|
100mm
|
|
Panel height
|
Up to 4000mm
|
Up to 6000mm
|
Up to 18000mm
|
|
Max height
|
4000mm
|
6000mm
|
18000mm
|
|
Panel width
|
600-1230mm
|
600-1230mm
|
600-1230mm
|
|
Frame construction
|
Aluminum frame
|
Aluminum frame
|
Aluminum frame
|
|
Face material
|
9mm
|
9mm / 12mm
|
12mm
|
|
Locking
|
Optional lock to pass doors
|
Optional lock to pass doors
|
Optional lock to pass doors
|
|
Pass doors
|
Single open in panel or
double open in two panel
|
Single open in panel or double open in two panel
|
Single open in panel or double open in two panel
|
|
Finish Material
|
Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting,etc. (Customized)
|
EBUNGE double,corrosion-resistant aluminum track systems are easy to install and easier to intain.
Extruding enables each section to have a uniform shape for superior end-to-end alignment.Each
capacity-certified track is of extruded architectural grade clear anodized 6063-T 6
Guangzhou Ebunge Partition Products Co.,Ltd established in 1998, is a professional manufacturer
engaged in development,sales,production and after-sales service of movable partition wall and office partition system.
The company have been certified product certification ISO 9001 quality system certification. there arew two
modern production bases occupies over 15000 square meters .
we have exported to 102 countries among which 100 five star hotels and commerical project completed.
1. Can I customize my own building material product for my house fromyour company?
-- Yes, you can.You just need supply your project drawing or purchasing list for us,we have a
professional team to give you the best design as your budget and requirements. If required,
we can also go to your project site for measurements and installation instructions.
2. Can you provide free sample?
-- Yes, we can provide the samples of product. All the sample cost will be refunded after y
ou place the order.
3. How about your lead time?--Our lead time is about 25-30 days.
4. Do you have your own factory?
-- Yes, we have our own Factory in Foshan, Guangdong Province.
5. How can i assure my payment?
-- You can place the order through Trade Assurance on Alibaba. For the details, please contact us.
6. What is your after-sale service?
-- After we deliver the goods, we will send the detailed drawings, installation instructions and packing list to tell you how to install. For any problems during installation, you can contact us at any time.
