Classroom Soundproof Acoustic Partition Wall / Conference Room Movable Partition

Classroom Soundproof Acoustic Partition Wall / Conference Room Movable Partition

Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO9001
Model Number: 65 mm classroom acoustic partition

Payment & Shipping Terms:

Minimum Order Quantity: No MOQ, small quantity welcomed
Price: US $78-95 per square meter
Packaging Details: Paper carton, outside with wooden boxes
Delivery Time: 12-20 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information
Product Name: Classroom Acoustic Partition Application: Conference Room Partitions
Size: Partition Walls Customized Style: Foldable
Pass Door: Single Or Double Contract Range: 22.5 Mm
High Light:

acoustic operable partitions

,

movable acoustic partition walls

Product Description

Conference Room Movable Partition Classroom Soundproof Acoustic Partition Walls Project Details



Classroom acoustic partition details



BUNGE classroom acoustic partitions are made of high quality anodized aluminum frame with environmentally composite materials.They just move on a ceiling track with no requirement of floor guides or rails.The classroom acoustic partitions have a standard thickness of 65mm,85mm and 100mm,and a width up to 1219mm.Maximum height can reach 17meter tall.Of course we will recommend a professional planning for you according to the height at your site.



The classroom acoustic partitions using sound-absorbing glass fiber,the fire resistance,thermal resistance and noise reduction coefficient are in line with the American ASTM standards.with top and bottom retractable mechanism in the middle,MDF,plywood or plaster base board are as base board on both sides.Also the aluminum tracks and tracks can be powder coated into different colors.



Nowadays,BUNGE Company works with Architects,designer,developers,contractors and owners in design product selection,decorative finishes,project management and 3 years after-sales warranty services as our one-stop solution business service.Actually all of the restaurant partition walls can be customized,including the size,the surfaces and the colors.For more information about the restaurant partition walls,please feel free to contact us at any time.

Classroom Soundproof Acoustic Partition Wall / Conference Room Movable Partition 0



Technical Information



Model BG-65 series BG-80 series BG-100 series BG-high series
Suspension system Aluminum hanging Aluminum hanging Aluminum hanging Steel hanging
Basic thickness 65mm 85mm 100mm 100mm
Total thickness 65/75/85/95mm 85/90/100/110mm 100/120/130mm 100/120/130mm
Max height Up to 3800mm Up to 4500mm Up to 6500mm Up to 12000mm
Width 600-1230mm 600-1230mm 800-1230mm 800-1230mm
Floor/ceiling sealing strength Telescopic aluminum tube with rubber strip
Side walls sealing strength Double seal tape
Sound insulation level 26dB-30dB 28dB-34dB 32-40dB 32-40dB
Panel structure Aluminum frame with wooden keel Aluminum frame with steel keel
Panel density 22-28kg/sqm. 24-32kg/sqm. 32-50kg/sqm. 40-68kg/sqm.
Surface material Melamine laminate/fabric/PU leather/wallpaper/veneer/customized

Classroom Soundproof Acoustic Partition Wall / Conference Room Movable Partition 1



FAQ



How to select the suitable classroom acoustic partitions for your site?



We have 4 types of classroom acoustic partition: 65type,85type,100type and 125 ultra-high type. You can choose the right movable wall upon the Height and Soundproof requirement as following:



65type---Max height:4500mm,Soundproof:32dB to 45dB



85type---Max height:5500m, Soundproof:40dB to 48dB



100type--Max height:7500mm,Soundproof:43dB to 53dB



125ultra-height---Max height:12500m,Soundproof: 43dB to 53dB

What you should do on site?



A beam(truss) should built on site for track installation.The min distance leaving for track installation from false ceiling to top ceiling is 250mm.

How to install the classroom acoustic partitions?



We will provide the installation manual and video guiding the installation job. We can also dispatch the installation engineer supervising the installation as request.

What is lead time?



The lead time is 15 days to 21 days.

How to transport the classroom acoustic partitions?



Sea transport is a common mode of transportation. In an emergency, can be air freight.



How do the goods packing?



Paper carton, outside with wooden box.


What is Procurement procedure?



Firstly, send us the shop drawings(if the shop drawings is not available, you can tell us the height from false ceiling to finished floor and width from wall to wall).



Secondly, we offer you the classroom acoustic partitions layout drawings for your confirmation.



Thirdly, we quote the classroom acoustic partitions in accordance with confirmed drawings.

What is finishing face?



The bottom panel is MDF or plywood, which is unfinished face. You can do decoration on site, such as wallpaper, paint, etc.


We can also provide the product with finished face, such as faux wood, Woven fabric and Leather.
