Aluminum Frame Restaurant Movable Partition Walls Acoustical Collapsible Wall

Aluminum Frame Restaurant Movable Partition Walls Acoustical Collapsible Wall

Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO 9001
Model Number: 65 mm collapsible movable partitions

Payment & Shipping Terms:

Minimum Order Quantity: NO MOQ, small quantity welcome
Price: $82-88 per square meter
Packaging Details: Paper carton, outside with wooden box
Delivery Time: 7-15 days
Payment Terms: T/T, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Collapsible Movable Partitions Application: Restaurant Partition Walls
Function: Room Dividion Package: Wooden Box
Color: Multiple Color Sample: Free
High Light:

movable walls on wheels

,

movable partitions systems

Product Description

Aluminum Frame Restaurant Movable Partition Walls Acoustical Collapsible Wall

Collapsible movable partitions components

Tracks: Made of good quality anodized aluminium 6063-T5 materials, hanging the movable walls panels with wheels.



Wheels/Rollers: It is the carrier for the collapsible movable partitions, let the panels move more flexibly. Pulley bearing is more than 1600 KGS.



Connectors: Made of anodized aluminium 6063-T5 aluminum tracks, “L”, “T”, “+”types are available.



Rubber/vinyl seal: Made of Nitrile Butadiene Rubber(NBR+PVC),durable and perfect for sound insulation, wear-resistant.



Rock Wool: Density of 50kg/m3, help us reduce the noise and heat.



Handle: Operate the retractable being up and down.



Retractable mechanism: Control the movement of the top and bottom seal to form a excellent sound insulation performance.



Magnetic Strip: Ferrite plastic magnetic material will be used in between aluminum profiles to enhance acoustic performance of the movable walls.



MDF board: 9 mm thickness, density of 760kg/m3, absorbent thickness expansion rate is less than 15%. Formaldehyde emission is 34mg/100g.

Decorative Modern Movable Sound Proof Office Partition Walls MDF + Aluminum Material



Technical Information



Series BG65 BG80 BG100
Panel suspension Top hung only
Track system Single or twin point
Panel thickness 65mm 80mm 100mm
Panel height Up to 3500mm Up to 5200mm Up to 17000mm
Max height 3500mm 5200mm 17000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire retardant as request
Retractable seals have
Adjustable panels Manual, with supplied operating handle
Pass doors Single door or double door as request
Sound insulation 32dB 40dB 50dB
Weight Approx 22-35kg/sqm Approx 25-40kg/sqm Approx30-48kg/sqm
Finish Material

Plywood, MDF, Laminate, Melamine, Gypsum board,

Fabric, Leather, Insulation board, Fireproof board,

Wall paper, Vinyl, Painting, etc. (Customized)

Aluminum Frame Restaurant Movable Partition Walls Acoustical Collapsible Wall 1



Collapsible movable partitions features



◆Individual panels that can be stored away for maximum space usage.



◆Operable top and bottom seals for effortless operation.



◆Aluminum frame construction for enhanced acoustics.



◆The system offers various levels of sound reduction.



◆Unique track and carrier system ensuring quiet and easy operation.



◆Numerous panel stacking options for complete flexibility.



◆Top hung and no floor track.



◆Extensive range of surface finishes can be availabled.

Aluminum Frame Restaurant Movable Partition Walls Acoustical Collapsible Wall 2
