Product Details:

Place of Origin: Guangzhou,China
Brand Name: BUNGE
Model Number: Series 65 mm folding partitions

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Price: 60-97 USD per square meter
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face.
Delivery Time: Shipped in 10 days after payment, based on the quantity.
Payment Terms: D/A, D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability: 5000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Folding Partition Wall Material: Aluminium Frame And Mdf Board
Height: Less Then 4 M Width: 500-1200 Mm
Thickness: 65mm Function: Space Divide,sound Proof
Application: Gallery,theater,office,banquet Hall,hotel Ect Warranty: 3-5 Years
High Light:

movable walls on wheels

,

movable partitions systems

Product Description

Manufacture new design movable partition walls office folding divider of china

Specification:

Aluminium Frame And MDF Board Movable Partition Walls Office Folding Divider 0

Specifications

1.Movable sound proof partition walls can separate the space speedy and conveniently.

2.Top hung system without the need for a floor track.

3.Folding partition wall is made from high density aluminum frame, special made rubber, excellent sound insulation cotton and finish surface, etc.

4.Around the panel, there is sound insulation rubber, it can help to insulate the sound entering.

5.The aluminium partition wall finished panel is hanging on the aluminum track, assembled with muti direction wheels.

6.Interlocking male / female trapezoidal vertical aluminium profiles, for soundproof connection between elements.



Technical parameters:

Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 80mm / 85mm 100mm
Panel height Up to 4000mm Up to 6000mm Up to 18000mm
Max height 4000mm 6000mm 18000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame Aluminum frame Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire safety Optional Class I or O Optional Class I or O Optional Class I or O
Vertical profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles
Retractable seals Aluminum black with
double rubber seals
Aluminum black with double rubber seals Aluminum black with double rubber seals
Operation of seals Manual, with supplied
operating handle
Manual, with supplied operating handle Manual, with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass doors Single open in panel or
double open in two panel
Single open in panel or double open in two panel Single open in panel or double open in two panel
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx30-48kg/sq M
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)



Finsh:

Different surface use in different areas.Our main surface is mdf melamine, it can be more easy to clean.Also fabric and leather surface is very popular in conference room or banquet hall.And like dancing room or classroom,client prefer mirror surface.Also we can design surface pu leather with printing photos.If client prefer to paint color on panels, we suggest Mdf bare finish.If prefer to glue wallpaper, plywood surface is a good choice.

Aluminium Frame And MDF Board Movable Partition Walls Office Folding Divider 1

Production:

We are a professional comprehensive office glass partition Manufacturer in Guangzhou, China, we make sure to offer the best solutions of space flexible. Each production process of our mobile partition products is strictly controlled to ensure quality to meet customer requirements.

Aluminium Frame And MDF Board Movable Partition Walls Office Folding Divider 2



Packing and shipping:

Our normal packing for movable partition wall is carton package, MDF batten on four section sides ,foam board on both front face.

If customer need OEM logo,it's also can be done.



    Free Sample in 10 Days       Inquiry now and you will have your sample in 10 day if you pay the express.                 3-year Warranty                     The acoustic room divider made of 6063-T5 alumina, anti-aging, no fading and abrasion in 10 years                 OEM Service                Your logo can be printed on the packaging carton



About us:

Guangdong Bunge Building Matarial Industrial Co.,Ltd is professional company in manufacturing movable partitions.It also artistically designs and carefully does research and development(R&D).The company has adopted the advance partition technology of USA,Germany and Denmark.We have professional staffs with more than 10 years of experience in design,production and installation.

Our product(movable partition)are widely used in the hotel,banquet hall,meeting room,exhibition hall,conference room,International convention center,KTV,upscale restaurants,office building,school,hospital and others.

Nowadays,the modern trend in building needs more flexibility and convenience to use the space of their rooms.Most of the building designers like to prepare open plan space,sound proof effect,and easy to operate.The solution of the designers need is the movable partition.

Bunge movable partition products as follow:
1.Ordinary Series:65MM,85MM;
2.High Sound Proof Series:85MM,100MM;
3.Super High Series:Steel Track System
4.Glass Series:65MM & 85MM Aluminum Frame

Aluminium Frame And MDF Board Movable Partition Walls Office Folding Divider 3



We have clients from all over the world,they are satisfied with our soundproof movable partition walls.

When they came to our factory, they all surprised at our environment and our technology.

There are a big movable wall show room in our factory, with different finish samples. Like glass partition, melamine partition, leather partition, fabric partition etc.

Aluminium Frame And MDF Board Movable Partition Walls Office Folding Divider 4
