Modern Fabric Movable Division Soundproof Folding Partition Walls For Office
Product Details:
| Place of Origin: | Guangzhou, China |
| Brand Name: | EBUNGE |
| Certification: | ISO 9001 |
| Model Number: | 65 mm folding fabric partitions |
|
Detail Information |
|||
| Product Name: | Folding Fabric Partitions | Application: | Office Partition Walls |
|---|---|---|---|
| Advantage: | Sound Proofing | Thickness: | 65 Mm(2 9/16 Inch) |
| Height: | 2-4 Meters | Frame: | Aluminum |
| High Light: | acoustic folding partition,folding room partitions |
||
Product Description
Modern Movable Division Soundproof Folding Fabric Partition Walls for Office
Folding fabric partitions details
We design and manufacture value for many products with one year's warranty on all the outstanding ranges illustrated in this brochure.
They offer a complete service package covering site surveys, CAD technical drawings, and quotation presentation. Emphasis is placed on quality assurance backed by a comprehensive after sales service.
Folding fabric partitions are specified where functional space delineation is an integral element within the partition project. Due to their flexibility and cost effectiveness they allow large rooms to be conveniently sub-divided to maximise space utilisation. Principle applications include office interiors, meeting rooms, sports and leisure facilities, schools, colleges, churches,conference and function suites, exhibition centres,banks and restaurants.
Folding fabric partition is a kind of activity wall that can divide a large space into a small space, or a small space into a large space at any time,according to needs, and has a general wall function. It can serve as a multi-purpose room with multiple functions.
Technical Information
| Panel Suspension | Top hunge system without the need for a floor track. | ||
| Panel Width | Each panel 600mm-1200mm. | ||
| Track | Aluminum OR Steel Track | ||
| Roller on panel | Single or Double Roller | ||
| Panel Frames | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. | ||
| Top&bottm seals | Top and bottom pressure retractable seals ensure effortless moved and locked. | ||
| Module | 700mm - 1200mm maximum. | ||
| Panel stacking | Numerous panel stacking options for complete flexibility. | ||
| Panel face | MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc. | ||
| Finishes | Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard. | ||
| Series | BG65 | BG80 | BG100 |
| Panel suspension | Top hung only | ||
| Track system | Single or twin point | ||
| Panel thickness | 65mm | 80mm | 100mm |
| Panel height | Up to 3500mm | Up to 5200mm | Up to 17000mm |
| Max height | 3500mm | 5200mm | 17000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | ||
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire retardant | as request | ||
| Retractable seals | have | ||
| Adjustable panels | Manual, with supplied operating handle | ||
| Pass doors | Single door or double door as request | ||
| Sound insulation | 32dB | 40dB | 50dB |
| Weight | Approx 22-35kg/sqm | Approx 25-40kg/sqm | Approx30-48kg/sqm |
| Finish Material |
Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) |
||
Folding fabric partitions features
Folding fabric partitions are specified where functional space delineation is an integral element within the partition project.
Due to their flexibility and cost effectiveness they allow large rooms to be conveniently sub-divided to maximize space utilization.
Principle applications include office interiors, meeting rooms, sports and leisure facilities, schools, colleges, churches, conference and function suites, exhibition centers, banks and restaurants.
